Tractor · 2013Unverified
Kubota L4760
Kubota L4760 — L60 Series · 49 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
49 hp
Weight
3847 to 4222 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Original price was $39,225 in 2025Reference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Two-post foldable ROPS. Grand Cab with air-conditioning available with hydrostatic.Reference
Variants
L4760DTGlide ShiftReference
L4760HSThydrostaticReference
L4760HSTChydro cabReference
Engine
Kubota 2.4L 4-cyl dieselReference
Fuel tank51.1 LReference
Engine (gross)36.5 kWReference
Engine (net)35.0 kWReference
KubotaReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.4 LReference
Bore/Stroke86 x 102 mmReference
EmissionsTier IVReference
Emission controlexhaust gas recirculation (EGR)Reference
Power (net)35.0 kWReference
Power (gross)36.5 kWReference
Fuel systemdirect injectionReference
Rated RPM2700 (gear)Reference
Rated RPM2600 (hydro)Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speedReference
TransmissionKubota Glide ShiftReference
Gears12 forward and 8 reverseReference
Clutchhydraulic dry discReference
TransmissionHST PlusReference
GearsHydrostatic transmission with three ranges plus Hydro Dual Speed Hi-Lo. The Dual Speed allows rapid switching between two speeds in range, either automatically or with a lever on the steering column. forward and hydrostatic reverseReference
Clutchinfinite (3-range)Reference
Transmissioninfinite (3-range)Reference
PTO & Hydraulics
PTO (claimed)30.6 kWReference
PTO (claimed)29.5 kWReference
Gear Pump flow37.1 lpmReference
Hydro Pump flow35.6 lpmReference
Gear Total flow55.6 lpmReference
Hydro Total flow53.4 lpmReference
Gear Steering flow18.5 lpmReference
Hydro Steering flow17.8 lpmReference
Rear TypeIReference
Controlposition control, draft control optionalReference
Rear lift (at 24"/610mm)1251 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Mid PTOoptionalReference
Mid PTO Type2000Reference
Dimensions
Wheelbase189 cmReference
Weight3847 to 4222 poundsReference
Front tire8.3-16Reference
Rear tire14.9-24Reference
Ag front8.3-16Reference
Ag rear14.9-24Reference
Length308 cmReference
Width168 cmReference
Height (ROPS)247 cmReference
Height (cab)231 cmReference
Ground clearance30 cmReference
Flange rear axleReference
Front tread130 cmReference
Rear tread128/143/152 cmReference
1744 kgReference
1744 kgReference
1915 kgReference
Kubota L4760 attachments
snowblowerReference
bladeReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
ROPS Charging amps40Reference
Cab Charging amps60Reference
Battery volts12Reference
Attachment overview
SnowblowerReference
BladeReference
Front-end loaderReference
BackhoeReference
Kubota BH92 Backhoe
Backhoe typeKubota BH92 BackhoeReference
Transport height254 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
Bucket width60 cmReference
Bucket width76 cmReference
Bucket width91 cmReference
Digging depth278 cmReference
Loading height214 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force2062 kgReference
Dipperstick force1223 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
