Tractor · 2022Unverified

Kubota L4802

Name: Kubota L4802
Brand: Kubota

Kubota L4802 — L02 Standard Series · 48 hp. Reference specifications; pending source verification.

The Kubota L4802 is a compact tractor rated at 48 hp. It was manufactured in 2022 and features a 4-cylinder diesel liquid-cooled engine. The L4802 is equipped with a hydrostatic transmission and four-wheel drive, and its weight is listed as 3296 to 3549 pounds. It is intended for use on land areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

48 hp

Max power

48.4 hp

Weight

3296 to 3549 pounds

Catalogue coverage

Variants represented

Richest spec table

119 rows

Recorded power

48 hp

Transmissions

8-speed mechanical shuttle

Production years

2022-2022

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Original price$23,733 (2023)Reference

Original price$24,925 (2026)Reference

Two- or four-wheel driveReference

Power steeringReference

Mechanical wet disc brakesReference

Two-post folding ROPS.Reference

Variants

L4802Nnarrow profileReference

Engine

Kubota 2.4L 4-cyl dieselReference

Fuel tank51.1 LReference

Engine (gross)36.1 kWReference

Engine (net)34.3 kWReference

KubotaReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.4 LReference

Bore/Stroke87 x 102 mmReference

Power (net)34.3 kWReference

Power (gross)36.1 kWReference

Fuel systemdirect injectionReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Fuel TypeDieselReference

No of Cylinders4Reference

Rated engine speed2,600 rpmReference

Bore and stroke87 x 102.4 mmReference

Transmission

8-speed mechanical shuttleReference

hydrostaticReference

2WD Gear1495 kgReference

4WD Gear1554 kgReference

Typemechanical shuttleReference

Gears8 forward and reverseReference

Clutchdry discReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

Transmission TypeHSTReference

forward and reverse options8x8 / 3 rangeReference

reverse speed range2.1 - 23.0 km/hReference

forward speed range2.2 - 24.0 km/hReference

Wheel Drive4WDReference

PTO & Hydraulics

Gear PTO (claimed)30.2 kWReference

Hydro PTO (claimed)29.1 kWReference

Typeopen centerReference

Pump flow29.5 lpmReference

Steering flow17.8 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at ends)1301 kgReference

Rear lift (at 24"/610mm)1052 kgReference

Rear PTOindependentReference

ClutchhydraulicReference

Rear PTO Type540 (1.375)Reference

Engine RPM540L2475 (gear)Reference

Engine RPM540@2640 (hydro)Reference

Dimensions

Wheelbase184 cmReference

Weight3296 to 3549 poundsReference

Front tire7.5L-15Reference

2WD Rear tire14.9-24Reference

2WD Standard tires (ag)Front: 7.5L-15. Rear: 14.9-24Reference

4WD Standard tires (ag)Front: 8.3-16. Rear: 14.9-24Reference

2WD Lawn/turf front27x8.50-15Reference

4WD Lawn/turf front27x10.5-15Reference

Lawn/turf rear44x18-20Reference

4WD Industrial front10.0-16.5Reference

4WD Industrial rear17.5L-24Reference

2WD Length311 cmReference

4WD Length305 cmReference

Width157 cmReference

Height (ROPS)232 cmReference

Ground clearance38 cmReference

2WD Front tread128 to 157 cmReference

4WD Front tread115 cmReference

Rear tread118 to 154 cmReference

4WD Hydro1609 kgReference

Kubota L4802 attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps45Reference

Charging volts12Reference

Battery CCA600Reference

Battery volts12Reference

Battery size12V, RC: 120 min, CCA: 6,000 AReference

Alternator size12V, 45AReference

Attachment overview

Front-end loaderReference

BackhoeReference

Kubota BH92 Backhoe

Backhoe typeKubota BH92 BackhoeReference

Transport height254 cmReference

2-Foot flat digging depth278 cmReference

Reach from pivot382 cmReference

Loading height214 cmReference

Bucket Rotation180°Reference

Capacities

Capacity2,434 ccReference

Power

Max Power48.4 hpReference

PTO

PTO Power40.5 hpReference

Rear PTO PoweryesReference

Rear PTO RPM540 rpmReference

Engine Speed on Rear PTO speed2,475 rpmReference

General

Cruise controltrueReference

Rear tread spacing1,545 mmReference

Steering & brakes

BrakesMechanical, wet disc typeReference

Steering typeHydrostatic power steeringReference

Hydraulics

Pump Rated Output (total)47.3 l/minReference

Hydraulics TypePosition controlReference

Maximum operating pressure180 kgf/cm2Reference

Steering & Implements flow17.9 lpm (29.4 lpm)Reference

Rear Hitch category (SAE designation)SAE Category IReference

Rear Hitch maximum lift capacity1,301.8 kgReference

Dimensions & weight

Overall Height2,330 mmReference

Overall Length3,120 mmReference

Overall Width1,580 mmReference

Turning radius8.9 feet (with Brakes)Reference

Overall weight1,609.8 kgReference

Wheels & tyres

Front Wheel TypeAG Standard 7.5 - 15 / AG Standard 8.5 - 15Reference

Front Wheel tread range1,580 mmReference

Operator station

Seat SuspensionAvailableReference
