Tractor · 2013Unverified

Kubota L5060

Name: Kubota L5060
Brand: Kubota

Kubota L5060 — L60 Series · 52 hp. Reference specifications; pending source verification.

The Kubota L5060 is a tractor model with an approximate engine rating of 52 hp, positioning it at the lighter end of its class. Production of this model spanned the period from 2013 to 2025. The tractor features a 4-cylinder turbocharged diesel liquid-cooled engine, paired with a four-wheel drive system and hydrostatic transmission. Its operating weight is listed at 1804 kg, with a capacity for operating on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

52 hp

Max power

52 hp

Weight

1804 kg

Catalogue coverage

Variants represented

Richest spec table

115 rows

Recorded power

52 hp

Recorded weight

1804 kg

Transmissions

12-speed

Production years

2013-2025

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Original price was $44,271Reference

Four-wheel driveReference

Steeringhydrostatic powerReference

Wet disc brakesReference

Two-post foldable ROPSReference

Engine

Kubota 2.4L 4-cyl dieselReference

Fuel tank51.1 LReference

Engine (gross)38.8 kWReference

Engine (net)37.3 kWReference

KubotaReference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.4 LReference

Bore/Stroke86 x 102 mmReference

EmissionsTier IVReference

Emission controlexhaust gas recirculation (EGR)Reference

Power (net)37.3 kWReference

Power (gross)38.8 kWReference

Fuel systemdirect injectionReference

Rated RPM2700Reference

StarterelectricReference

Starter volts12Reference

Fuel TypeDieselReference

No of Cylinders4Reference

Rated engine speed2,700 rpmReference

Bore and stroke87 X 102.4 mmReference

Transmission

12-speedReference

TransmissionKubota Glide ShiftReference

Gears12 forward and 8 reverseReference

Clutchhydraulic dry discReference

Transmission TypeSemi-PowershiftReference

forward and reverse options12x8Reference

forward speed range1.5 - 26.5 km/hReference

reverse speed range1.5 - 25.3 km/hReference

Wheel Drive4WDReference

PTO & Hydraulics

PTO (claimed)32.8 kWReference

Pump flow37.1 lpmReference

Total flow55.6 lpmReference

Steering flow18.5 lpmReference

Rear TypeIReference

Controlposition control, draft control optionalReference

Rear lift (at 24"/610mm)1349 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Mid PTOoptionalReference

Mid PTO Type2000Reference

Dimensions

Wheelbase191 cmReference

Weight1804 kgReference

Front tire9.5-16Reference

Rear tire14.9-26Reference

Ag front9.5-16Reference

Ag rear14.9-26Reference

Length321 cmReference

Width170 cmReference

Height (ROPS)248 cmReference

Ground clearance39 cmReference

Flange rear axleReference

Front tread134 cmReference

Rear tread132/143 cmReference

Kubota L5060 attachments

snowblowerReference

bladeReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps45Reference

Battery volts12Reference

Battery size12 VReference

Alternator size12 VReference

Attachment overview

SnowblowerReference

BladeReference

Front-end loaderReference

BackhoeReference

Kubota BH92 Backhoe

Backhoe typeKubota BH92 BackhoeReference

Transport height254 cmReference

Bucket width30 cmReference

Bucket width40 cmReference

Bucket width60 cmReference

Bucket width76 cmReference

Bucket width91 cmReference

Digging depth278 cmReference

Loading height214 cmReference

Bucket Rotation180°Reference

Swing Arc180°Reference

Bucket force2062 kgReference

Dipperstick force1223 kgReference

Capacities

Capacity2,434 ccReference

Power

Max Power52 hpReference

PTO

PTO Power44 hpReference

Rear PTO PowerTRUEReference

Rear PTO ControlIndependentReference

Rear PTO RPM540 rpmReference

Mid PTO RPM2,000 rpmReference

General

Cruise controltrueReference

SCV controlJoystickReference

Rear tread spacing1,430 mmReference

Steering & brakes

BrakesWet disc typeReference

Steering typeHydrostatic power steeringReference

Hydraulics

Pump Rated Output (total)55.6 l/minReference

Hydraulics Type3-point: Category I & IIReference

Steering & Implements flow18.6 lpm (37 lpm)Reference

Rear Hitch category (SAE designation)Category I & IIReference

Dimensions & weight

Overall Height2,490 mmReference

Overall Length3,210 mmReference

Overall Width1,710 mmReference

Turning radius9.2 feet (with Brakes)Reference

Overall weight1,804.8 kgReference

Wheels & tyres

Rear Wheel Type14.9-24Reference

Front Wheel Type9.5-16Reference

Front Wheel tread range1,340 mmReference

Operator station

Cab AvailabilityOptionalReference

Seat SuspensionAvailableReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
