Tractor · 2026Unverified

Kubota L5070

Name: Kubota L5070
Brand: Kubota

Kubota L5070 — L70 Series · 50 hp. Reference specifications; pending source verification.

The Kubota L5070 is a tractor with a power rating of approximately 50 hp, categorising it as a lighter model in its class. It was manufactured in 2026. The tractor features a 4-cylinder turbocharged diesel liquid-cooled engine, paired with four-wheel drive and a hydrostatic transmission. Its operating weight ranges from 4266 to 4663 pounds, and it is suitable for operations of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

50 hp

Weight

4266 to 4663 pounds

Catalogue coverage

Variants represented

Richest spec table

61 rows

Recorded power

50 hp

Recorded weight

1935 kg

Transmissions

hydrostatic

Production years

2026-2026

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Original price was $46,253 in 2026Reference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS. Cab optional with air-conditioning.Reference

Engine

Kubota 2.4L 4-cyl dieselReference

Engine (gross)37.3 kWReference

Kubota V2403Reference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.4 LReference

Bore/Stroke87 x 102 mmReference

Power (gross)37.3 kWReference

Fuel systemcommon rail direct injectionReference

Rated RPM2300Reference

Torque195.7 NmReference

StarterelectricReference

Starter volts12Reference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

PTO & Hydraulics

PTO (claimed)29.7 kWReference

Rear valves3Reference

Pump flow37.2 lpmReference

Rear TypeIReference

Rear lift (at ends)1749 kgReference

Rear lift (at 24"/610mm)1250 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2299Reference

Dimensions

Wheelbase204 cmReference

Weight4266 to 4663 poundsReference

Front tire8.3-16Reference

Rear tire14.9-24Reference

Standard tires (ag)Front: 8.3-16. Rear: 14.9-24Reference

Length328 cmReference

Width168 cmReference

Height (ROPS)247 cmReference

Height (cab)233 cmReference

ROPS Weight1935 kgReference

Cab Weight2115 kgReference

Ground clearance36 cmReference

Front tread132 cmReference

Rear tread128 to 152 cmReference

Kubota L5070 attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Battery CCA582Reference

Battery CCA680Reference

Battery volts12Reference

Attachment overview

Front-end loaderReference

BackhoeReference

Kubota BH92A Backhoe

Backhoe typeKubota BH92A BackhoeReference

Transport height260 cmReference

2-Foot flat digging depth265 cmReference

Reach from pivot381 cmReference

Loading height224 cmReference

Bucket Rotation180°Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
