Tractor · 1991Unverified
Kubota L5450
Kubota L5450 — Utility tractor · 60 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
60 hp
Weight
2000 kg
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post fixed ROPS.Reference
Engine
Kubota 2.7L 5-cyl dieselReference
Engine (gross)44.4 kWReference
Kubota F2803-DIReference
dieselReference
5-cylinderReference
liquid-cooledReference
Displacement2.7 LReference
Bore/Stroke86 x 91 mmReference
Power (gross)44.4 kWReference
Rated RPM2600Reference
Starter volts12Reference
Starter power1.4 kWReference
Oil capacity8.0 LReference
Coolant capacity8.0 LReference
Transmission
8-speed mechanical shuttleReference
8-speed hydraulic shuttleReference
Typemechanical shuttleReference
Gears8 forward and reverseReference
Clutchdry discReference
Oil capacity43.1 LReference
Four gears in two ranges with reverser lever.Reference
Typehydraulic shuttleReference
Clutchwet discReference
PTO & Hydraulics
PTO (claimed)36.5 kWReference
Hydraulic system43.1 LReference
Typeopen centerReference
Capacity43.1 LReference
Pump flow49.2 lpmReference
Rear TypeII/IReference
Controlposition and draft controlReference
Rear lift (at ends)1496 kgReference
Rear lift (at 24"/610mm)1451 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Rear PTO Type1000Reference
Engine RPM540@2305Reference
Engine RPM1000@2471Reference
Capacities
Fuel60.2 LReference
Front hubs2.7 LReference
Front diff.6.2 LReference
Dimensions
Wheelbase194 cmReference
Weight2000 kgReference
Front tire9.5-20Reference
Rear tire14.9-28Reference
Ag front9.5-20Reference
Ag rear14.9-28Reference
Length348 cmReference
Width171 cmReference
Height (steering wheel)157 cmReference
Max Drawbar997 kgReference
Ground clearance36 cmReference
Front tread137 cmReference
Rear tread132 to 182 cmReference
Kubota L5450 attachments
front-end loaderReference
backhoeReference
L5450 Serial Number Location
Serial number plate on the left side of the Kubota L5450 transmission housing, on the operator platform.Reference
L5450 Serial Numbers
198960004Reference
199060348Reference
199160545Reference
199260595Reference
199360851Reference
199461071Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH110Reference
Battery AH160Reference
Attachment overview
Kubota BF1100 loaderReference
Kubota LA1150 loaderReference
Kubota LA1150A loaderReference
BackhoeReference
The Kubota L5450 was recommended with three 14-inch plows, two 16-inch, or a single 18-inch. Rotary cutters up to 84-inches were recommended.Reference
Kubota L4540A Backhoe
Backhoe typeKubota L4540A BackhoeReference
Transport height262 cmReference
Bucket width33 cmReference
Bucket width45 cmReference
Bucket width60 cmReference
Bucket width76 cmReference
Bucket width91 cmReference
Digging depth344 cmReference
Reach from pivot425 cmReference
Loading height250 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1564 kgReference
Dipperstick force1242 kgReference
Kubota L5412 Backhoe
Backhoe typeKubota L5412 BackhoeReference
Transport height279 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
Bucket width45 cmReference
Bucket width60 cmReference
Digging depth335 cmReference
Reach from pivot419 cmReference
Loading height274 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force3007 kgReference
Dipperstick force1592 kgReference
Speeds
With 14.9-28 R1 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
