Tractor · 2013Unverified

Kubota L6060

Name: Kubota L6060
Brand: Kubota

Kubota L6060 — L60 Series · 62 hp. Reference specifications; pending source verification.

The Kubota L6060 is a tractor with a rating of approximately 62 hp, positioning it at the lower end of its class. It was produced between 2013 and 2025. The tractor features a 4-cylinder turbocharged diesel liquid-cooled engine, paired with four-wheel drive and a hydrostatic transmission. Its operating weight ranges from 3990 to 4365 pounds, suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

62 hp

Max power

62 hp

Weight

3990 to 4365 pounds

Catalogue coverage

Variants represented

Richest spec table

122 rows

Recorded power

62 hp

Recorded weight

1809 kg

Transmissions

hydrostatic

Production years

2013-2025

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Original price was $44,440 in 2025Reference

Four-wheel driveReference

Steeringhydrostatic powerReference

Wet disc brakesReference

Two-post foldable ROPS. Grand Cab with air-conditioning optional.Reference

Variants

L6060HSTROPSReference

L6060HSTCcabReference

Engine

Kubota 2.4L 4-cyl dieselReference

Fuel tank51.1 LReference

Engine (gross)46.2 kWReference

Engine (net)44.7 kWReference

KubotaReference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.4 LReference

Bore/Stroke86 x 102 mmReference

EmissionsTier IVReference

Emission controlexhaust gas recirculation (EGR)Reference

Power (net)44.7 kWReference

Power (gross)46.2 kWReference

Fuel systemdirect injectionReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Fuel TypeDieselReference

No of Cylinders4Reference

Rated engine speed2,600 rpmReference

Bore and stroke87 X 102.4 mmReference

Transmission

hydrostaticReference

TransmissionHST Plus Hydrostatic transmission with three ranges plus Hydro Dual Speed Hi-Lo. The Dual Speed allows rapid switching between two speeds in range, either automatically or with a lever on the steering column.Reference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

Transmission TypeHSTReference

forward and reverse options3 rangesReference

forward speed range3.4 - 16.2 km/hReference

reverse speed range3.1 - 14.6 km/hReference

Wheel Drive4WDReference

ClutchDry type single stageReference

PTO & Hydraulics

PTO (claimed)39.5 kWReference

Pump flow35.6 lpmReference

Total flow53.4 lpmReference

Steering flow17.8 lpmReference

Rear TypeIReference

Controlposition control, draft control optionalReference

Rear lift (at 24"/610mm)1349 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Mid PTOoptionalReference

Mid PTO Type2000Reference

Dimensions

Wheelbase191 cmReference

Weight3990 to 4365 poundsReference

Front tire9.5-16Reference

Rear tire14.9-26Reference

Ag front9.5-16Reference

Ag rear14.9-26Reference

Length321 cmReference

Width170 cmReference

Height (ROPS)248 cmReference

Height (cab)234 cmReference

ROPS Weight1809 kgReference

Cab Weight1979 kgReference

Ground clearance39 cmReference

Flange rear axleReference

Front tread134 cmReference

Rear tread132/143 cmReference

Kubota L6060 attachments

snowblowerReference

bladeReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

ROPS Charging amps45Reference

Cab Charging amps60Reference

Battery volts12Reference

Battery size12 VReference

Alternator size12 VReference

Attachment overview

SnowblowerReference

BladeReference

Front-end loaderReference

BackhoeReference

Kubota BH92 Backhoe

Backhoe typeKubota BH92 BackhoeReference

Transport height254 cmReference

Bucket width30 cmReference

Bucket width40 cmReference

Bucket width60 cmReference

Bucket width76 cmReference

Bucket width91 cmReference

Digging depth278 cmReference

Loading height214 cmReference

Bucket Rotation180°Reference

Swing Arc180°Reference

Bucket force2062 kgReference

Dipperstick force1223 kgReference

Capacities

Capacity2,434 ccReference

Power

Max Power62 hpReference

PTO

PTO Power53 hpReference

Rear PTO PowerTRUEReference

Rear PTO ControlIndependentReference

Rear PTO RPM540 rpmReference

Mid PTO RPM2,000 rpmReference

General

Cruise controltrueReference

SCV controlJoystickReference

Rear tread spacing1,430 mmReference

Steering & brakes

BrakesWet disc typeReference

Steering typeHydrostatic power steeringReference

Hydraulics

Pump Rated Output (total)53.5 l/minReference

Hydraulics Type3-point: Category I and IIReference

Steering & Implements flow17.9 lpm (35.6 lpm)Reference

Rear Hitch category (SAE designation)Category I & IIReference

Dimensions & weight

Overall Height2,490 mmReference

Overall Length3,210 mmReference

Overall Width1,710 mmReference

Turning radius9.2 feet (with Brakes)Reference

Overall weight1,979.9 kgReference

Wheels & tyres

Rear Wheel Type14.9-24Reference

Front Wheel Type9.5-16Reference

Front Wheel tread range1,340 mmReference

Operator station

Cab AvailabilityOptionalReference

Seat SuspensionAvailableReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
