Tractor · 2026Unverified

Kubota L6070

Name: Kubota L6070
Brand: Kubota

Kubota L6070 — L70 Series · 60 hp. Reference specifications; pending source verification.

The Kubota L6070 tractor model has a rated power output of 60 hp, positioning it at the lighter end of its class. It features a 4-cylinder turbocharged intercooled diesel liquid-cooled engine, paired with a four-wheel drive system that utilises a hydrostatic transmission. The operating weight of the Kubota L6070 ranges from 4387 to 4762 pounds, and it is suitable for operations covering up to 200 acres. This model was manufactured in 2026.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

60 hp

Weight

4387 to 4762 pounds

Catalogue coverage

Variants represented

Richest spec table

61 rows

Recorded power

60 hp

Recorded weight

1989 kg

Transmissions

hydrostatic

Production years

2026-2026

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Original price was $52,200 in 2026Reference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS. Cab optional with air-conditioning.Reference

Engine

Kubota 2.4L 4-cyl dieselReference

Engine (gross)44.7 kWReference

Kubota V2403Reference

turbocharged intercooled dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.4 LReference

Bore/Stroke87 x 102 mmReference

Power (gross)44.7 kWReference

Fuel systemcommon rail direct injectionReference

Rated RPM2300Reference

Torque245.0 NmReference

StarterelectricReference

Starter volts12Reference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

PTO & Hydraulics

PTO (claimed)39.5 kWReference

Rear valves3Reference

Pump flow37.2 lpmReference

Rear TypeII/IReference

Rear lift (at ends)1749 kgReference

Rear lift (at 24"/610mm)1349 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2258Reference

Dimensions

Wheelbase206 cmReference

Weight4387 to 4762 poundsReference

Front tire9.5-16Reference

Rear tire14.9-26Reference

Standard tires (ag)Front: 9.5-16. Rear: 14.9-26Reference

Length340 cmReference

Width170 cmReference

Height (ROPS)248 cmReference

Height (cab)236 cmReference

ROPS Weight1989 kgReference

Cab Weight2160 kgReference

Ground clearance39 cmReference

Front tread132 cmReference

Rear tread132 to 143 cmReference

Kubota L6070 attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Battery CCA582Reference

Battery CCA680Reference

Battery volts12Reference

Attachment overview

Front-end loaderReference

BackhoeReference

Kubota BH92A Backhoe

Backhoe typeKubota BH92A BackhoeReference

Transport height260 cmReference

2-Foot flat digging depth265 cmReference

Reach from pivot381 cmReference

Loading height224 cmReference

Bucket Rotation180°Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
