Tractor · 2020Unverified

Kubota LX2610

Name: Kubota LX2610
Brand: Kubota

Kubota LX2610 — LX Series · 25 hp. Reference specifications; pending source verification.

The Kubota LX2610 is a tractor with a rating of approximately 25 hp, positioning it within the lighter end of its class. It was manufactured in 2020. The tractor is powered by a 3-cylinder diesel liquid-cooled engine, paired with four-wheel drive and a hydrostatic transmission. Its operating weight is listed as between 1830 and 2293 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

25 hp

Weight

1830 to 2293 pounds

Catalogue coverage

Variants represented

Richest spec table

113 rows

Recorded power

25 hp

Recorded weight

501 kg

Transmissions

hydrostatic

Production years

2020-2020

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Compact Utility tractorReference

Original price$17,175 (2020 ROPS )Reference

Original price$24,823 (2020 Cab )Reference

Four-wheel driveReference

Final drivesspur gearReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS. Cab available with air-conditioning.Reference

Variants

LX2610SUno mid PTOReference

Engine

Kubota 1.3L 3-cyl dieselReference

ROPS Fuel tank26.9 LReference

Cab Fuel tank31.8 LReference

Engine (gross)18.5 kWReference

Kubota D1305Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.3 LReference

Bore/Stroke78 x 88 mmReference

Power (gross)18.5 kWReference

Air cleanerdual dry elementReference

Rated RPM2500Reference

StarterelectricReference

Starter volts12Reference

Coolant capacity4.3 LReference

Fuel TypeDieselReference

No of Cylinders3-cylinderReference

Rated engine speed2,500Reference

Bore and stroke3.07x3.46 inchesReference

Cooling systemliquid-cooledReference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

Oil capacity11.4 LReference

forward and reverse optionsinfinite (3-range) forward and reverseReference

Rear Axle Drive Typespur gearReference

PTO & Hydraulics

PTO (claimed)14.5 kWReference

Typeopen centerReference

Rear valves0 to 2Reference

Pump flow18.9 lpmReference

Total flow32.9 lpmReference

Steering flow14.0 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at ends)970 kgReference

Rear lift (at 24"/610mm)760 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2398Reference

Mid PTOindependentReference

Mid PTO Type2500Reference

Engine RPM2500@2500Reference

Dimensions

Wheelbase166 cmReference

Weight1830 to 2293 poundsReference

Front tire7-12Reference

Rear tire12.4-16Reference

Weight501 kgReference

Standard tires (ag)Front: 7-12. Rear: 12.4-16Reference

Industrial front23x8.50-14Reference

Industrial front25x8.50-14Reference

Industrial front23x8.50-12 (R14)Reference

Industrial rear12.4-16Reference

Industrial rear15-19.5Reference

Industrial rear14-17.5 (R-14)Reference

ROPS Length258 cmReference

Cab Length263 cmReference

Width136 cmReference

Height (ROPS)224 cmReference

Height (cab)214 cmReference

ROPS Weight830 kgReference

Cab Weight1040 kgReference

Ground clearance37 cmReference

Kubota LX2610 attachments

60" mid-mount mower deckReference

72" mid-mount mower deckReference

snowblowerReference

bladeReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

ROPS Charging amps40Reference

Cab Charging amps60Reference

Battery CCA430Reference

Battery volts12Reference

Total cold cranking amps430Reference

Attachment overview

60" mid-mount mower deckReference

72" mid-mount mower deckReference

SnowblowerReference

BladeReference

Front-end loaderReference

BackhoeReference

Kubota BH77 Backhoe

Backhoe typeKubota BH77 BackhoeReference

Transport height204 cmReference

2-Foot flat digging depth233 cmReference

Reach from pivot316 cmReference

Loading height169 cmReference

Swing Arc180°Reference

General

Make & ModelKubotaReference

Country of manufacturerCompact Utility tractorReference

Capacities

Capacity77 ciReference

PTO

Rear PTO PowerAvailableReference

Steering & brakes

Brakeswet discReference

Steering typepowerReference

Hydraulics

Hydraulics Typeopen centerReference

Steering & Implements flow3.7 gpm (5.0 gpm)Reference

Rear Hitch category (SAE designation)Category IReference

Rear Hitch maximum lift capacity970.2 kgReference

Rear Hitch Sensing Typeposition controlReference

Dimensions & weight

Overall Height224.5 cmReference

Overall Width136.4 cmReference

Operator station

Cab AvailabilityAvailableReference

Cab Air conditioning, temperature differentialTwo-post folding ROPS. Cab available with air-conditioning.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
