Tractor · 1988Unverified
Kubota M1-46
Kubota M1-46 — M1 Series · 43 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
43 hp
Weight
2249 kg
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Utility tractorReference
Four-wheel driveReference
Four-post ROPS. Cab optional.Reference
Engine
Kubota 2.4L 5-cyl dieselReference
Fuel tank60.2 LReference
Engine34.3 kWReference
Kubota F2402Reference
dieselReference
5-cylinderReference
liquid-cooledReference
Displacement2.4 LReference
Bore/Stroke87 x 82 mmReference
Power34.3 kWReference
Rated RPM2600Reference
Torque159.9 NmReference
Torque RPM1600Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speedReference
18-speed creeperReference
Gears12 forward and reverseReference
Six gears in two ranges with shuttle.Reference
TypecreeperReference
Gears18 forward and reverseReference
PTO & Hydraulics
PTO (claimed)31.8 kWReference
Rear TypeJIS1Reference
Rear TypeJIS2Reference
Rear lift1999 kgReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@2194Reference
Engine RPM1000@2520Reference
Dimensions
Wheelbase197 cmReference
Weight2249 kgReference
Front tire8.3Reference
Rear tire20:12.4-28Reference
Standard tires (ag)Front: 8.3. Rear: 20Reference
Length357 cmReference
Width176 cmReference
Height242 cmReference
Clearance (rear axle)34 cmReference
Front tread135 to 139 cmReference
Rear tread121 to 192 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
