Tractor · 2009Unverified

Kubota M100X

Kubota M100X — Row-Crop tractor · 100 hp. Reference specifications; pending source verification.

The Kubota M100X is a tractor with a rated power of 100 hp, falling within the mid-range for its class. The model was manufactured from 2009 to 2014. It features a 4-cylinder turbocharged diesel liquid-cooled engine and four-wheel drive, coupled with a hydrostatic transmission. The tractor has a listed operating weight of 4020 kg and is suitable for operations covering 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
100 hp
Max power
65.0 kW
Weight
4020 kg

Catalogue coverage

Variants represented
2
Richest spec table
119 rows
Recorded power
100 hp
Recorded weight
4020 kg
Transmissions
16-speed partial powershift
Production years
2009-2014
Verified variants
0

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference
Row-Crop tractorReference
Original price$54,758 (2011)Reference
Four-wheel driveReference
Differential lockelectro-hydraulic front and rearReference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
Cab standard with heat and air-conditioning. Optional radio/CD-player.Reference

Engine

Kubota 3.8L 4-cyl dieselReference
Engine (gross)74.6 kWReference
Engine (net)72.9 kWReference
Kubota V3800-TI-CRSReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.8 LReference
Bore/Stroke100 x 120 mmReference
Power (net)72.9 kWReference
Power (gross)74.6 kWReference
Air cleanerdual dry elementReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity10.5 LReference
Coolant capacity9.0 LReference
Max power65.0 kWReference
Power at rated engine speed63.5 kWReference
Fuel TypedieselReference
No of Cylinders4 cylinderReference
Rated engine speed2,600 RPMReference
Bore and stroke3.94x4.72 inchesReference
Cooling systemliquid-cooledReference

Transmission

16-speed partial powershiftReference
24-speedReference
TransmissionIntelli-ShiftReference
Typepartial powershiftReference
Gears16 forward and reverseReference
Clutchelectro-hydraulic wet discsReference
Oil capacity59.8 LReference
Eight-speed power shift two-range mechanical shift operated via clutch button.Reference
TransmissionIntell-Shift CreeperReference
Gears24 forward and reverseReference
Transmission TypeSemi-PowershiftReference
forward and reverse optionsIntelli-Shift 16F and 16R | Intell-Shift Creeper 24F and 24RReference
Wheel Drive4WDReference

PTO & Hydraulics

PTO (claimed)63.4 kWReference
PTO (tested)65.0 kWReference
Hydraulic system59.8 LReference
Typeopen centerReference
Capacity59.8 LReference
Pressure196.1 barReference
Valves2 to 4Reference
Pump flow68.5 lpmReference
Total flow133.6 lpmReference
Steering flow65.1 lpmReference
Rear TypeIIReference
Rear lift (at ends)2634 kgReference
Rear lift (at 24"/610mm)2360 kgReference
Rear lift (at 24"/610mm)4285 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@2035Reference
Engine RPM1000@2210Reference
Power at rated PTO speed63.8 kWReference

Capacities

Fuel190.0 LReference
Front axle10.5 LReference
Fuel tank190 LReference
Crankcase oil volume11.1 qtsReference

Dimensions

Wheelbase243 cmReference
Weight4020 kgReference
Front tire12.4R24Reference
Rear tire18.4R30Reference
Standard tires (ag)Front: 12.4R24. Rear: 18.4R30Reference
Optional tires (ag)Front: 13.6-24. Rear: 18.4-34Reference
Optional tires (ag)Front: 13.6R24. Rear: 18.4R34Reference
Optional tires (ag)Front: 12.4-24. Rear: 18.4-30Reference
Optional tires (ag)Front: 12.4-24. Rear: 16.9-34Reference
Length424 cmReference
Width212 cmReference
Height263 cmReference
Ground clearance55 cmReference
Front tread157 to 167 cmReference
Rear tread157 to 203 cmReference

Kubota M100X attachments

front-end loaderReference

Electrical

GroundnegativeReference
Charging systemalternatorReference
Charging amps80Reference
Battery CCA900Reference
Battery volts12Reference
Total cold cranking amps900 CCAReference

Attachment overview

Kubota LA1953 Height Position loaderReference
Kubota LA1953 Power Position loaderReference

Test results

Diesel 16-speed 4WDOctober 29 - November 4, 2010Link: Nebraska Tractor Test 1979 fileReference
PTO performanceReference
Fuel use20.8 l/hourReference
Fuel use21.2 l/hourReference
Fuel use19.7 l/hourReference

General

Make & ModelKubotaReference

Power

Rated Power97.7 hpReference

PTO

PTO Power85 hpReference
Rear PTO PowerAvailableReference
Rear PTO RPM1,000 RPMReference
Engine Speed on Rear PTO speed1,000@2,210 RPMReference

Steering & brakes

Brakeshydraulic wet discReference
Steering typehydrostatic powerReference

Hydraulics

Pump Rated Output (total)35.3 gpmReference
Hydraulics Typeopen centerReference
Maximum operating pressure2,844 psiReference
Remote Valves2 to 4 ValvesReference
Steering & Implements flow17.2 gpm (18.1 gpm)Reference
Rear Hitch category (SAE designation)Category IIReference
Rear Hitch maximum lift capacity2,634.9 kgReference

Dimensions & weight

Overall Height263.9 cmReference
Overall Length424.2 cmReference
Overall Width212.6 cmReference
Overall weight4,020.2 kgReference

Wheels & tyres

Rear wheel tread range62.2 to 80.1 inchesReference
Front Wheel tread range62.2 to 66.1 inchesReference

Operator station

Cab AvailabilityAvailableReference
