The Kubota M105D is a tractor rated at approximately 104 horsepower, a mid-range figure for its class. Production of the M105D took place between 2005 and 2008. The tractor features a 4-cylinder turbocharged diesel liquid-cooled engine, combined with four-wheel drive and a powershift transmission. Its listed operating weight is 3640 kg, and it is suitable for operations of up to 200–800 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
104 hp
Weight
3640 kg
Catalogue coverage
Variants represented
2
Richest spec table
50 rows
Recorded power
104 hp
Recorded weight
3640 kg
Transmissions
16-speed power shift
Production years
2005-2008
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Utility tractorReference
Four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Kubota 3.8L 4-cyl dieselReference
Fuel tank190.0 LReference
Engine77.2 kWReference
Kubota V3800-TIReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.8 LReference
Bore/Stroke100 x 120 mmReference
Power77.2 kWReference
Fuel systemdirect injectionReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed power shiftReference
24-speed creeperReference
Typepower shiftReference
Gears16 forward and reverseReference
Clutchhydraulic wet discReference
Eight power-shift gears in two ranges with shuttle.Reference
TypecreeperReference
Gears24 forward and reverseReference
Optional creeper adds an additional 8-speed range to the standard transmission.Reference
PTO & Hydraulics
Rear TypeIIReference
Controlposition and electronic draft controlReference
Rear lift2800 kgReference
Rear lift3900 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Engine RPM540@2205Reference
Engine RPM1000@2389Reference
Dimensions
Wheelbase243 cmReference
Weight3640 kgReference
Front tire11.2-24Reference
Rear tire16.9-34Reference
Standard tires (ag)Front: 11.2-24. Rear: 16.9-34Reference
Length405 cmReference
Width196 cmReference
Height264 cmReference
Ground clearance45 cmReference
Front tread133 to 151 cmReference
Rear tread139 to 200 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
