Tractor · 2016Unverified

Kubota M105GX-III

Name: Kubota M105GX-III
Brand: Kubota

Kubota M105GX-III — MGX III Series · 111 hp. Reference specifications; pending source verification.

The Kubota M105GX-III tractor has a rated power output of approximately 111 hp, placing it in the mid-range of its class. It was produced between 2016 and 2018. The tractor is equipped with a 4-cylinder turbocharged intercooled diesel liquid-cooled engine, coupled with four-wheel drive and a powershift transmission. Its listed operating weight is 4300 kg, and it is suitable for operations spanning 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

111 hp

Max power

111 hp

Weight

4300 kg

Catalogue coverage

Variants represented

Richest spec table

92 rows

Recorded power

111 hp

Recorded weight

4300 kg

Transmissions

24-speed 8-speed power shift

Production years

2016-2018

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Utility tractorReference

Four-wheel driveReference

Differential lockelectro-hydraulic front and rearReference

Power steeringReference

Hydraulic wet disc brakesReference

Cab standard with air-conditioning.Reference

Engine

Kubota 3.8L 4-cyl dieselReference

Fuel tank190.0 LReference

Exhaust fluid (DEF)15.9 LReference

Engine (gross)82.8 kWReference

Kubota V3800-CRReference

turbocharged intercooled dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.8 LReference

Bore/Stroke100 x 120 mmReference

EmissionsStage IVReference

Rated Power (gross)82.8 kWReference

Rated RPM2400Reference

Torque379.7 NmReference

Torque RPM1500Reference

StarterelectricReference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders4 CylinderReference

Rated engine speed2,400 RPMReference

Emissions complianceStage IVReference

Engine torque at rated speed127 kgReference

Bore and stroke3.94x4.72 inchesReference

Cooling systemliquid-cooledReference

Transmission

24-speed 8-speed power shiftReference

32-speed creeperReference

Type8-speed power shiftReference

Gears24 forward and reverseReference

Clutchelectro-hydraulic wet discReference

Eight power shift gears in three synchronized ranges with shuttle.Reference

TypecreeperReference

Gears32 forward and reverseReference

Transmission TypePowershiftReference

forward and reverse options8-speed power shift - 24F and 24R | creeper - 32F and 32RReference

Wheel Drive4WDReference

PTO & Hydraulics

Valves2 to 4Reference

Pump flow76.5 lpmReference

Rear TypeIIIReference

Controlposition and lower-link draft controlReference

Rear lift (at ends)5000 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Rear PTO Type540/540EReference

Front PTOindependentReference

Front PTO Type1000Reference

Dimensions

Wheelbase243 cmReference

Weight4300 kgReference

Front tire380/70R24Reference

Rear tire520/70R34Reference

Standard tires (ag)Front: 380/70R24. Rear: 520/70R34Reference

Length430 cmReference

Width227 cmReference

Height282 cmReference

Front tread156 to 167 cmReference

Rear tread175/184/183 cmReference

Kubota M105GX-III attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Attachment overview

Kubota LA1955 loaderReference

General

Make & ModelKubotaReference

Cruise controlAvailableReference

SCV controlJoystickReference

Capacities

Capacity230 ciReference

Diesel exhaust fluid (DEF) tank15.9 LReference

Power

Max Power111 hpReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Front PTO PowerAvailableReference

Steering & brakes

Brakeshydraulic wet discReference

Steering typepowerReference

Hydraulics

Remote Valves2 to 4 ValvesReference

Rear Hitch category (SAE designation)Category IIIReference

Rear Hitch maximum lift capacity4,999.9 kgReference

Rear Hitch Sensing Typeposition and lower-link draft controlReference

Dimensions & weight

Overall Height283 cmReference

Overall Length430.5 cmReference

Overall Width227.6 cmReference

Overall weight4,300.1 kgReference

Wheels & tyres

Rear Wheel Type520/70R34Reference

Rear wheel tread range68.9/72.8/72.2 inchesReference

Front Wheel Type380/70R24Reference

Front Wheel tread range61.6 to 65.9 inchesReference

Operator station

Cab AvailabilityAvailableReference

Seat SuspensionTRUEReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
