Tractor · 2007Unverified
Kubota M108SDSL
Kubota M108SDSL — Orchard/Vineyard tractor · 108 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
108 hp
Weight
2960 kg
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Orchard/Vineyard tractorReference
Original price$43,992 (2011)Reference
The dual 540/1000 RPM PTO is noted on by the M108SDSL2 model code. Optional adjustable height orchard steel fenders in wide (M108SDSL-S) or narrow (M108SDSL-SN) sizes.Reference
Four-wheel driveReference
Differential lockmechanical front and rearReference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
Two-post folding ROPS. Optional canopy.Reference
Variants
M108XIntelli-ShiftReference
M108SSwing ShiftReference
M108SDSLlow-profileReference
Engine
Kubota 3.8L 4-cyl dieselReference
Engine (net)80.5 kWReference
Kubota V3800-DT-TIReference
turbocharged intercooled dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.8 LReference
EmissionsTier IIIReference
Power (net)80.5 kWReference
Air cleanerdual dry elementReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity10.7 LReference
Coolant capacity9.1 LReference
Transmission
32-speed partial power shiftReference
48-speedReference
TransmissionSwing Shift PlusReference
Typepartial power shiftReference
Gears32 forward and reverseReference
Clutchhydraulic wet discsReference
Oil capacity62.8 LReference
Four synchronized gears in two synchronized ranges with additional non-synchronized range. Left-hand hydraulic shuttle shift. Dual Speed provides push-button high-low shift for each speed.Reference
TransmissionSwing Shift Plus with CreeperReference
Gears48 forward and reverseReference
PTO & Hydraulics
PTO (claimed)71.6 kWReference
Hydraulic system62.8 LReference
Typeopen centerReference
Capacity62.8 LReference
Pressure196.1 barReference
Valves1 to 3Reference
Pump flow65.1 lpmReference
Total flow110.9 lpmReference
Steering flow45.8 lpmReference
Rear TypeIIReference
Rear lift (at ends)2522 kgReference
Rear lift (at 24"/610mm)2100 kgReference
Rear lift (at 24"/610mm)2748 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@2205Reference
Capacities
Fuel174.9 LReference
Front axle10.5 LReference
Dimensions
Wheelbase243 cmReference
Weight2960 kgReference
Front tire9.5-20Reference
Rear tire16.9-24Reference
Standard tires (ag)Front: 9.5-20. Rear: 16.9-24Reference
Optional tires (ag)Front: 12.5/80-18. Rear: 16.9-24Reference
Optional tires (ag)Front: 9.5-24. Rear: 18.4-26Reference
Industrial front14-18.5Reference
Industrial rear19.5L-24Reference
Length406 cmReference
Width213 cmReference
Height (ROPS)231 cmReference
Height (ROPS)175 cmReference
Clearance (drawbar)30 cmReference
Front tread152 cmReference
Rear tread168 to 199 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps45Reference
Charging amps80 (optional)Reference
Battery CCA900Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
