Tractor · 2014Unverified
Kubota M110G-PC Power Crawler
Kubota M110G-PC Power Crawler — Globe Series · 109 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
109 hp
Weight
5059 kg
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Half-track Crawler tractorReference
Drivehalf-trackReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with air-conditioning.Reference
Variants
M110Gwheeled[9743]Reference
M110G-PChalf-track crawlerReference
Engine
Kubota 3.8L 4-cyl dieselReference
Fuel tank190.0 LReference
Engine80.9 kWReference
Kubota V3800-CR-TIE4Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.8 LReference
Bore/Stroke100 x 120 mmReference
Power80.9 kWReference
Fuel systemdirect injectionReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speed power shiftReference
32-speed creeperReference
Typepower shiftReference
Gears24 forward and reverseReference
Clutchhydraulic wet discReference
Eight power-shift gears in three ranges with shuttle.Reference
TypecreeperReference
Gears32 forward and reverseReference
Optional creeper adds an additional 8-speed range to the standard transmission.Reference
PTO & Hydraulics
Rear TypeIIReference
Controlposition and electronic draft controlReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Engine RPM540@2405Reference
Engine RPM1000@2529Reference
Dimensions
Wheelbase243 cmReference
Weight5059 kgReference
Front tire13.6-24Reference
Rear tiretracksReference
Ag front13.6-24Reference
Ag rear400mm trackReference
Length426 cmReference
Width202 cmReference
Height282 cmReference
Ground clearance40 cmReference
Front tread152 cmReference
Rear tread157 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
