Tractor · 2009Unverified

Kubota M110X

Kubota M110X — Row-Crop tractor · 110 hp. Reference specifications; pending source verification.

The Kubota M110X is a tractor rated at approximately 110 horsepower, a typical output for its class. This model was manufactured from 2009 to 2014. It features a 4-cylinder turbocharged diesel liquid-cooled engine, paired with four-wheel drive and a hydrostatic transmission. The tractor's operating weight is 4105 kilograms.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
110 hp
Max power
110 hp
Weight
4105 kg

Catalogue coverage

Variants represented
2
Richest spec table
116 rows
Recorded power
110 hp
Recorded weight
4105 kg
Transmissions
16-speed partial powershift
Production years
2009-2014
Verified variants
0

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference
Row-Crop tractorReference
Original price$60,124 (2011 )Reference
Original price$62,860 (2012 )Reference
Four-wheel driveReference
Differential lockelectro-hydraulic front and rearReference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
Cab standard with heat and air-conditioning. Optional radio/CD-player.Reference

Engine

Kubota 3.8L 4-cyl dieselReference
Engine (gross)82.0 kWReference
Engine (net)80.2 kWReference
Kubota V3800-TI-CRSReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.8 LReference
Bore/Stroke100 x 120 mmReference
EmissionsTier IIIReference
Power (net)80.2 kWReference
Power (gross)82.0 kWReference
Air cleanerdual dry elementReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity10.5 LReference
Coolant capacity9.0 LReference
Fuel TypedieselReference
No of Cylinders4 cylinderReference
Rated engine speed2,600 RPMReference
Emissions complianceTier IIIReference
Bore and stroke3.94x4.72 inchesReference
Cooling systemliquid-cooledReference

Transmission

16-speed partial powershiftReference
24-speedReference
TransmissionIntelli-ShiftReference
Typepartial powershiftReference
Gears16 forward and reverseReference
Clutchelectro-hydraulic wet discsReference
Oil capacity59.8 LReference
Eight-speed power shift two-range mechanical shift operated via clutch button.Reference
TransmissionIntell-Shift CreeperReference
Gears24 forward and reverseReference
Transmission TypeSemi-PowershiftReference
forward and reverse optionsIntelli-Shift 16F and 16R | Intell-Shift Creeper 24F and 24RReference
Wheel Drive4WDReference

PTO & Hydraulics

PTO (claimed)70.8 kWReference
Hydraulic system59.8 LReference
Typeopen centerReference
Capacity59.8 LReference
Pressure196.1 barReference
Valves2 to 4Reference
Pump flow68.5 lpmReference
Total flow133.6 lpmReference
Steering flow65.1 lpmReference
Rear TypeIIReference
Rear lift (at ends)2634 kgReference
Rear lift (at 24"/610mm)2360 kgReference
Rear lift (at 24"/610mm)4285 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@2035Reference
Engine RPM1000@2210Reference

Capacities

Fuel190.0 LReference
Front axle10.5 LReference
Fuel tank190 LReference
Crankcase oil volume11.1 qtsReference

Dimensions

Wheelbase243 cmReference
Weight4105 kgReference
Front tire13.6R24Reference
Rear tire18.4R34Reference
Standard tires (ag)Front: 13.6R24. Rear: 18.4R34Reference
Optional tires (ag)Front: 13.6-24. Rear: 18.4-34Reference
Optional tires (ag)Front: 13.6R24. Rear: 18.4R34Reference
Optional tires (ag)Front: 12.4-24. Rear: 18.4-30Reference
Optional tires (ag)Front: 12.4-24. Rear: 16.9-34Reference
Length424 cmReference
Width212 cmReference
Height268 cmReference
Ground clearance58 cmReference
Front tread157 to 167 cmReference
Rear tread157 to 203 cmReference

Kubota M110X attachments

front-end loaderReference

Electrical

GroundnegativeReference
Charging systemalternatorReference
Charging amps80Reference
Battery CCA900Reference
Battery volts12Reference
Total cold cranking amps900 CCAReference

Attachment overview

Kubota LA1953 Height Position loaderReference
Kubota LA1953 Power Position loaderReference

General

Make & ModelKubotaReference

Power

Max Power110 hpReference
Rated Power107.5 hpReference

PTO

PTO Power95 hpReference
Rear PTO PowerAvailableReference
Rear PTO RPM1,000 RPMReference
Engine Speed on Rear PTO speed1,000@2,210 RPMReference

Steering & brakes

Brakeshydraulic wet discReference
Steering typehydrostatic powerReference

Hydraulics

Pump Rated Output (total)35.3 gpmReference
Hydraulics Typeopen centerReference
Maximum operating pressure2,844 psiReference
Remote Valves2 to 4 ValvesReference
Steering & Implements flow17.2 gpm (18.1 gpm)Reference
Rear Hitch category (SAE designation)Category IIReference
Rear Hitch maximum lift capacity2,634.9 kgReference

Dimensions & weight

Overall Height269 cmReference
Overall Length424.2 cmReference
Overall Width212.6 cmReference
Overall weight4,105 kgReference

Wheels & tyres

Rear Wheel Type18.4R34Reference
Rear wheel tread range62.2 to 80.1 inchesReference
Front Wheel Type13.6R24Reference
Front Wheel tread range62.2 to 66.1 inchesReference

Operator station

Cab AvailabilityAvailableReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
