The Kubota M115G is a tractor with a rated power output of 114 hp, placing it in the middle of its class. It was manufactured in 2014. The tractor is equipped with a 4-cylinder turbocharged diesel liquid-cooled engine, which drives through a four-wheel drive system with a powershift transmission. Its listed operating weight is 4340 kg, with a suitable working area of approximately 200-800 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
114 hp
Weight
4340 kg
Catalogue coverage
Variants represented
2
Richest spec table
50 rows
Recorded power
114 hp
Recorded weight
4340 kg
Transmissions
24-speed power shift
Production years
2014-2014
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Utility tractorReference
Four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with air-conditioning.Reference
Variants
M115GwheeledReference
M115G-PChalf-track crawlerReference
Engine
Kubota 6.1L 4-cyl dieselReference
Fuel tank190.0 LReference
Engine84.6 kWReference
Kubota V6108-CR-TIE4Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement6.1 LReference
Bore/Stroke118 x 140 mmReference
Power84.6 kWReference
Fuel systemdirect injectionReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speed power shiftReference
32-speed creeperReference
Typepower shiftReference
Gears24 forward and reverseReference
Clutchhydraulic wet discReference
Eight power-shift gears in three ranges with shuttle.Reference
TypecreeperReference
Gears32 forward and reverseReference
Optional creeper adds an additional 8-speed range to the standard transmission.Reference
PTO & Hydraulics
Rear TypeIIReference
Controlposition and electronic draft controlReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Engine RPM540@1994Reference
Engine RPM1000@2050Reference
Dimensions
Wheelbase268 cmReference
Weight4340 kgReference
Front tire13.6R24Reference
Rear tire420/85R38Reference
Standard tires (ag)Front: 13.6R24. Rear: 420/85R38Reference
Length436 cmReference
Width210 cmReference
Height283 cmReference
Ground clearance43 cmReference
Front tread164/173 cmReference
Rear tread157 to 205 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
