Tractor · 1998Unverified
Kubota M120
Kubota M120 — M Series · 100 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
100 hp
Max power
76.9 kW
Weight
9040 to 9700 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Utility tractorReference
During official testing, the Kubota M120DT failed to meet claimed hydraulic flow and three-point lift, with the basic hitch lifting 3,280 pounds (instead of 5,200).Reference
Two- or four-wheel driveReference
Differential lockelectro-hydraulic front and rearReference
Power steeringReference
Differential hydraulic wet discs brakesReference
Cab standard with air-conditioning.Reference
Variants
M120DT4WDReference
Engine
Kubota 5.8L 5-cyl dieselReference
Engine89.5 kWReference
Drawbar (tested)66.6 kWReference
Kubota F5802Reference
turbocharged dieselReference
5-cylinderReference
liquid-cooledReference
Displacement5.8 LReference
Bore/Stroke109 x 125 mmReference
Power89.5 kWReference
Fuel systemdirect injectionReference
Air cleanerdual paper elementsReference
Rated RPM2400Reference
Torque461.0 NmReference
Torque RPM1300Reference
Starter volts12Reference
Coolant capacity13.6 LReference
Max power76.9 kWReference
Power at rated engine speed74.8 kWReference
Max power66.6 kWReference
Transmission
16-speed eight-speed power shiftReference
24-speed creeperReference
Typeeight-speed power shiftReference
Gears16 forward and reverseReference
Clutchelectro-hydraulic wet discReference
Eight-speed push-button power shift with two ranges (low/high). Push-button clutch button for range shifts. Electro-hydraulic power shuttle.Reference
TypecreeperReference
Gears24 forward and reverseReference
PTO & Hydraulics
PTO (claimed)73.1 kWReference
PTO (tested)76.9 kWReference
Hydraulic system57.7 LReference
Typeopen centerReference
Capacity57.7 LReference
Valves2Reference
Pump flow78.0 lpmReference
Rear TypeIIReference
Rear lift2358 kgReference
Rear lift2980 kgReference
Rear lift3601 kgReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@2035Reference
Engine RPM1000@2210Reference
Power at rated PTO speed76.3 kWReference
Capacities
Fuel199.8 LReference
Dimensions
2WD Wheelbase263 cmReference
4WD Wheelbase268 cmReference
Weight9040 to 9700 poundsReference
Front tire11.00-16Reference
2WD Rear tire18.4R-38Reference
2WD Standard tires (ag)Front: 11.00-16. Rear: 18.4R-38Reference
4WD Standard tires (ag)Front: 14.9-24. Rear: 18.4R-38Reference
Length436 cmReference
Width219 cmReference
Height (cab)272 cmReference
Clearance (front axle)61 cmReference
2WD4100 kgReference
4WD4399 kgReference
Ballasted5889 kgReference
Kubota M120 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
Kubota LA1301 loaderReference
Kubota LA1601 loaderReference
Test results
Diesel 16-speed 4WDMay 1 - 31, 1999Link: OCED Tractor Test 1841 fileReference
PTO performanceReference
Fuel use23.5 l/hourReference
Fuel use24.2 l/hourReference
Fuel use23.1 l/hourReference
Drawbar performanceReference
Gear 2H used for power test.Reference
Max pull5699 kgReference
Gear 3L used for pull test.Reference
Speeds
With 18.4-38 rear tires.Reference
