Tractor · 2014Unverified
Kubota M125G-PC Power Crawler
Kubota M125G-PC Power Crawler — Globe Series · 123 hp. Reference specifications; pending source verification.
The Kubota M125G-PC Power Crawler is a high-powered tractor, boasting a rated output of 123 hp. Introduced in 2014, it is equipped with a 4-cylinder turbocharged diesel liquid-cooled engine, which drives a tracked undercarriage via a powershift transmission. The tractor's listed weight is 5450 kg, and it is designed for use on plots of around 200–800 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
123 hp
Weight
5450 kg
Catalogue coverage
Variants represented
2
Richest spec table
47 rows
Recorded power
123 hp
Recorded weight
5450 kg
Transmissions
24-speed power shift
Production years
2014-2014
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Half-track Crawler tractorReference
Drivehalf-trackReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with air-conditioning.Reference
Variants
M125GwheeledReference
M125G-PChalf-track crawlerReference
Engine
Kubota 6.1L 4-cyl dieselReference
Fuel tank190.0 LReference
Engine91.9 kWReference
Kubota V6108-CR-TIE4Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement6.1 LReference
Bore/Stroke118 x 140 mmReference
Power91.9 kWReference
Fuel systemdirect injectionReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speed power shiftReference
Typepower shiftReference
Gears24 forward and reverseReference
Clutchhydraulic wet discReference
Eight power-shift gears in three ranges with shuttle.Reference
PTO & Hydraulics
Rear TypeIIReference
Controlposition and electronic draft controlReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Engine RPM540@1994Reference
Engine RPM1000@2050Reference
Dimensions
Wheelbase268 cmReference
Weight5450 kgReference
Front tire13.6-24Reference
Rear tiretracksReference
Ag front13.6-24Reference
Ag rear400mm trackReference
Length451 cmReference
Width217 cmReference
Height282 cmReference
Ground clearance41 cmReference
Front tread173 cmReference
Rear tread178 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
