Tractor · 2009Unverified

Kubota M126X

Name: Kubota M126X
Brand: Kubota

Kubota M126X — Row-Crop tractor · 126 hp. Reference specifications; pending source verification.

The Kubota M126X is a high-powered tractor rated at 126 hp, positioning it in the higher-powered segment of its class. Manufactured from 2009 to 2014, this model features a 4-cylinder turbocharged, intercooled diesel engine, which is liquid-cooled and powers four-wheel drive through a hydrostatic transmission. The listed weight of the M126X is 4599 kg, and it is designed for tasks involving areas of approximately 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

126 hp

Max power

126 hp

Weight

4599 kg

Catalogue coverage

Variants represented

Richest spec table

111 rows

Recorded power

126 hp

Recorded weight

4599 kg

Transmissions

16-speed partial powershift

Production years

2009-2014

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Row-Crop tractorReference

Original price$67,174 (2011)Reference

Four-wheel driveReference

Differential lockelectro-hydraulic front and rearReference

Steeringhydrostatic powerReference

Hydraulic wet disc brakesReference

Cab standard with heat and air-conditioning. Optional radio/CD-player.Reference

Variants

M126Xwheeled tractorReference

Engine

M126X Power Krawlerhalf-trackReference

Kubota 6.1L 4-cyl dieselReference

Engine (gross)94.0 kWReference

Engine (net)93.2 kWReference

Kubota V6108-TI-CRSReference

turbocharged intercoolec dieselReference

4-cylinderReference

liquid-cooledReference

Displacement6.1 LReference

Bore/Stroke118 x 140 mmReference

Power (net)93.2 kWReference

Power (gross)94.0 kWReference

Air cleanerdual dry elementReference

Rated RPM2200Reference

StarterelectricReference

Starter volts12Reference

Oil capacity14.6 LReference

Coolant capacity15.0 LReference

Fuel TypedieselReference

No of Cylinders4 cylinderReference

Rated engine speed2,200 RPMReference

Bore and stroke4.65x5.51 inchesReference

Cooling systemliquid-cooledReference

Transmission

16-speed partial powershiftReference

24-speedReference

TransmissionIntelli-ShiftReference

Typepartial powershiftReference

Gears16 forward and reverseReference

Clutchelectro-hydraulic wet discsReference

Oil capacity59.8 LReference

Eight-speed power shift two-range mechanical shift operated via clutch button.Reference

TransmissionIntell-Shift CreeperReference

Gears24 forward and reverseReference

Transmission TypeSemi-PowershiftReference

Wheel Drive4WDReference

PTO & Hydraulics

PTO (claimed)80.5 kWReference

Hydraulic system59.8 LReference

Typeopen centerReference

Capacity59.8 LReference

Valves2 to 4Reference

Pump flow77.2 lpmReference

Total flow135.1 lpmReference

Steering flow57.9 lpmReference

Rear TypeIIReference

Rear lift (at ends)2634 kgReference

Rear lift (at 24"/610mm)2360 kgReference

Rear lift (at 24"/610mm)4285 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000 (1.375)Reference

Engine RPM540@2035Reference

Engine RPM1000@2210Reference

Capacities

Fuel190.0 LReference

Front axle16.6 LReference

Fuel tank190 LReference

Crankcase oil volume15.4 qtsReference

Dimensions

Wheelbase268 cmReference

Weight4599 kgReference

Front tire14.9R24Reference

Rear tire18.4R38Reference

Standard tires (ag)Front: 14.9R24. Rear: 18.4R38Reference

Optional tires (ag)Front: 420/70R24. Rear: 520/80R38Reference

Optional tires (ag)Front: 13.6-24. Rear: 16.9-38Reference

Length436 cmReference

Width226 cmReference

Height272 cmReference

Ground clearance61 cmReference

Front tread177 to 186 cmReference

Rear tread159 to 209 cmReference

Kubota M126X attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps80Reference

Battery CCA1090Reference

Battery volts12Reference

Total cold cranking amps1,090 CCAReference

Attachment overview

Kubota LA2253 Height Position loaderReference

Kubota LA2253 Power Position loaderReference

General

Make & ModelKubotaReference

Power

Max Power126 hpReference

Rated Power125 hpReference

PTO

PTO Power108 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM1,000 RPMReference

Engine Speed on Rear PTO speed1,000@2,210 RPMReference

Steering & brakes

Brakeshydraulic wet discReference

Steering typehydrostatic powerReference

Hydraulics

Pump Rated Output (total)35.7 gpmReference

Hydraulics Typeopen centerReference

Remote Valves2 to 4 ValvesReference

Steering & Implements flow15.3 gpm (20.4 gpm)Reference

Rear Hitch category (SAE designation)Category IIReference

Rear Hitch maximum lift capacity2,634.9 kgReference

Dimensions & weight

Overall Height272.5 cmReference

Overall Length436.1 cmReference

Overall Width226.1 cmReference

Overall weight4,599.9 kgReference

Wheels & tyres

Rear Wheel Type18.4R38Reference

Rear wheel tread range62.6 to 82.3 inchesReference

Front Wheel Type14.9R24Reference

Front Wheel tread range69.7 to 73.6 inchesReference

Operator station

Cab AvailabilityAvailableReference

Seat SuspensionTRUEReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
