Tractor · 2016Unverified

Kubota M135GX-III

Name: Kubota M135GX-III
Brand: Kubota

Kubota M135GX-III — MGX III Series · 143 hp. Reference specifications; pending source verification.

The Kubota M135GX-III is a high-powered tractor model, rated at 143 hp. It was manufactured from 2016 to 2018. Features include a 4-cylinder turbocharged intercooled diesel liquid-cooled engine, a powershift transmission and four-wheel drive. The listed weight for this model is between 10604 and 11089 pounds, suitable for tracts of land ranging from 200 to 800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

143 hp

Max power

143 hp

Weight

10604 to 11089 pounds

Catalogue coverage

Variants represented

Richest spec table

96 rows

Recorded power

143 hp

Recorded weight

4809 kg

Transmissions

24-speed 8-speed power shift

Production years

2016-2018

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Utility tractorReference

Four-wheel driveReference

Differential lockelectro-hydraulic front and rearReference

Power steeringReference

Hydraulic wet disc brakesReference

Cab standard with air-conditioning.Reference

Engine

Kubota 6.1L 4-cyl dieselReference

Fuel tank190.0 LReference

Exhaust fluid (DEF)15.9 LReference

Engine (gross)106.6 kWReference

Kubota V6108-CRReference

turbocharged intercooled dieselReference

4-cylinderReference

liquid-cooledReference

Displacement6.1 LReference

Bore/Stroke118 x 140 mmReference

EmissionsStage IVReference

Rated Power (gross)106.6 kWReference

Rated RPM2200Reference

Torque585.8 NmReference

Torque RPM1500Reference

StarterelectricReference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders4 CylinderReference

Rated engine speed2,200 RPMReference

Emissions complianceStage IVReference

Engine torque at rated speed196 kgReference

Bore and stroke4.65x5.51 inchesReference

Cooling systemliquid-cooledReference

Transmission

24-speed 8-speed power shiftReference

32-speed creeperReference

Type8-speed power shiftReference

Gears24 forward and reverseReference

Clutchelectro-hydraulic wet discReference

Eight power shift gears in three synchronized ranges with shuttle.Reference

TypecreeperReference

Gears32 forward and reverseReference

Transmission TypePowershiftReference

forward and reverse options8-speed power shift - 24F and 24R | creeper - 32F and 32RReference

Wheel Drive4WDReference

PTO & Hydraulics

Valves2 to 4Reference

Pump flow82.5 lpmReference

Rear TypeIIIReference

Controlposition and lower-link draft controlReference

Rear lift (at ends)6100 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Rear PTO Type540/540EReference

Front PTOindependentReference

Front PTO Type1000Reference

Dimensions

Wheelbase268 cmReference

Wheelbase267 cmReference

Weight10604 to 11089 poundsReference

Front tire420/70R24Reference

Rear tire520/70R38Reference

Standard tires (ag)Front: 420/70R24. Rear: 520/70R38Reference

Length446 cmReference

Width210 cmReference

Height288 cmReference

Weight4809 kgReference

Weight5029 kgReference

Front tread171 to 176 cmReference

Rear tread160/166/175/181/185 cmReference

Kubota M135GX-III attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Attachment overview

Kubota LA2255 loaderReference

General

Make & ModelKubotaReference

Cruise controlAvailableReference

SCV controlJoystickReference

Capacities

Capacity373.7 ciReference

Diesel exhaust fluid (DEF) tank15.9 LReference

Power

Max Power143 hpReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Front PTO PowerAvailableReference

Steering & brakes

Brakeshydraulic wet discReference

Steering typepowerReference

Hydraulics

Remote Valves2 to 4 ValvesReference

Rear Hitch category (SAE designation)Category IIIReference

Rear Hitch maximum lift capacity6,099.9 kgReference

Rear Hitch Sensing Typeposition and lower-link draft controlReference

Dimensions & weight

Overall Height288.5 cmReference

Overall Length446 cmReference

Overall Width210.1 cmReference

Overall weight5,029.9 kgReference

Wheels & tyres

Rear Wheel Type520/70R38 agReference

Rear wheel tread range63.2/65.4/69.1/71.3/73.2 inchesReference

Front Wheel Type420/70R24 agReference

Front Wheel tread range67.7 to 69.5 inchesReference

Operator station

Cab AvailabilityAvailableReference

Cab Air conditioning, temperature differentialCab standard with air-conditioning.Reference

Seat SuspensionTRUEReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
