Tractor · 2019Unverified

Kubota M4-061

Name: Kubota M4-061
Brand: Kubota

Kubota M4-061 — M4 Series · 65 hp. Reference specifications; pending source verification.

The Kubota M4-061 is a tractor with a rated power of 65 hp, falling within the mid-range for its class. It was manufactured in 2019 and features a 4-cylinder turbocharged diesel liquid-cooled engine, paired with four-wheel drive and a 12-speed gearbox. The tractor has an operating weight of 2725 kg and is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

65 hp

Weight

2725 kg

Catalogue coverage

Variants represented

Richest spec table

68 rows

Recorded power

65 hp

Recorded weight

2725 kg

Transmissions

12-speed power shuttle

Production years

2019-2019

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Utility tractorReference

Original price was $50,018 in 2019Reference

Four-wheel driveReference

Power steeringReference

Hydraulic wet disc brakesReference

Cab standard with air-conditioning.Reference

Engine

Kubota 3.3L 4-cyl dieselReference

Engine (gross)48.8 kWReference

Kubota V3307-CR-TE4Reference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.3 LReference

Bore/Stroke94 x 119 mmReference

Rated Power (gross)48.8 kWReference

Fuel systemcommon rail direct injectionReference

Rated RPM2400Reference

StarterelectricReference

Starter volts12Reference

Oil capacity12.0 LReference

Coolant capacity10.0 LReference

Transmission

12-speed power shuttleReference

18-speed creeperReference

Typepower shuttleReference

Gears12 forward and reverseReference

Clutchwet discReference

Six synchronized gears in two ranges with left-hand hydraulic shuttle. Push-button clutch for gear shifts.Reference

TypecreeperReference

Gears18 forward and reverseReference

Optional creeper adds an additional range to the standard shuttle transmission.Reference

PTO & Hydraulics

PTO (claimed)38.8 kWReference

Hydraulic system40.1 LReference

Typeopen centerReference

Capacity40.1 LReference

Valves2 to 3Reference

Pump flow63.2 lpmReference

Steering flow23.8 lpmReference

Rear TypeII/IReference

Controlposition control and top-link draft sensingReference

Rear lift (at 24"/610mm)1500 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulicReference

Rear PTO Type540/540E (1.375)Reference

Capacities

Fuel90.1 LReference

Dimensions

Wheelbase213 cmReference

Weight2725 kgReference

Front tire320/85R20Reference

Rear tire420/85R30Reference

Standard tires (ag)Front: 320/85R20. Rear: 420/85R30Reference

Lawn/turf front9.50-24Reference

Lawn/turf rear18.4-26Reference

Industrial front14-17.5Reference

Industrial rear16.9-24Reference

Length360 cmReference

Width192 cmReference

Height (cab)256 cmReference

Clearance (front axle)45 cmReference

Front tread148 cmReference

Rear tread142/174 cmReference

Kubota M4-061 attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps130Reference

Battery CCA900Reference

Battery volts12Reference

Attachment overview

Kubota LA1154A loaderReference

Speeds

With 420/85R30 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
