Tractor · 1988Unverified
Kubota M4030SU
Kubota M4030SU — M30 Series · 51 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
51 hp
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Utility tractorReference
Two-wheel driveReference
Power steeringReference
Mechanical wet disc brakesReference
Two-post ROPS.Reference
Engine
Kubota 2.4L 5-cyl dieselReference
Fuel tank64.0 LReference
Engine (gross)38.0 kWReference
Kubota F2402-DI-AReference
dieselReference
5-cylinderReference
liquid-cooledReference
Displacement2.4 LReference
Power (gross)38.0 kWReference
Fuel systemdirect injectionReference
StarterelectricReference
Starter volts12Reference
Transmission
8-speedReference
16-speed creeperReference
Gears8 forward and 2 reverseReference
Four gears (1-4) in two ranges (low/high).Reference
TypecreeperReference
Gears16 forward and 4 reverseReference
PTO & Hydraulics
PTO (claimed)31.3 kWReference
Typeopen centerReference
Rear TypeIReference
Rear PTOindependentReference
Rear PTO Type540Reference
Engine RPM540@2194Reference
Dimensions
Wheelbase199 cmReference
Front tire6.00-16Reference
Standard tires (ag)Front: 6.00-16. Rear:Reference
Optional tires (ag)Front: 13.6-28. Rear:Reference
Lawn/turf front29x12.50-15 (Turf Special)Reference
Lawn/turf rear21.5-16.1 (Turf Special)Reference
Length341 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
