Tractor · 2018Unverified
Kubota M4072
Kubota M4072 — M4002 Series · 74 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
74 hp
Weight
5666 to 6702 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Utility tractorReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post folding ROPS. Cab optional.Reference
Engine
Kubota 3.3L 4-cyl dieselReference
Engine (gross)55.2 kWReference
Kubota V3307Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke94 x 119 mmReference
EmissionsStage IVReference
Rated Power (gross)55.2 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
18-speedReference
36-speedReference
Gears18 forward and reverseReference
Clutchwet discReference
Gears36 forward and reverseReference
PTO & Hydraulics
Valves2 or 3Reference
Pump flow62.8 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift (at ends)2500 kgReference
Rear PTOindependentReference
Rear PTO Type540/540EReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase213 cmReference
Weight5666 to 6702 poundsReference
Front tire320/85R20Reference
Rear tire420/85R30Reference
Standard tires (ag)Front: 320/85R20. Rear: 420/85R30Reference
Length370 cmReference
ROPS Width184 cmReference
Cab Width195 cmReference
Height (cab)258 cmReference
ROPS Weight2570 kgReference
Cab Weight3040 kgReference
ROPS Front tread145 to 153 cmReference
Cab Front tread136 to 141 cmReference
ROPS Rear tread143 to 172 cmReference
Cab Rear tread152 to 174 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
