Tractor · 1995Unverified
Kubota M4700
Kubota M4700 — M Series · 51 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
51 hp
Weight
3748 to 3968 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Utility tractorReference
Two- or four-wheel driveReference
Power steeringReference
Mechanical wet disc brakesReference
Two-post ROPS.Reference
Engine
Kubota 2.7L 5-cyl dieselReference
Engine (gross)38.0 kWReference
Engine (net)35.0 kWReference
Kubota F2803Reference
dieselReference
5-cylinderReference
liquid-cooledReference
Displacement2.7 LReference
Bore/Stroke87 x 92 mmReference
Power (net)35.0 kWReference
Power (gross)38.0 kWReference
Rated RPM2600Reference
Torque158.0 NmReference
Torque RPM1600Reference
Starter volts12Reference
Coolant capacity6.2 LReference
Oil capacity8.0 LReference
Oil change100 hReference
Transmission
8-speed partially synchronizedReference
12-speed creeperReference
Typepartially synchronizedReference
Gears8 forward and 4 reverseReference
Clutchdry discReference
Oil capacity40.0 LReference
Oil typeKubota Super UDTReference
Four gears (1-4) in two ranges (low/high) plus reverse range. Synchronized shifting between gears 3 and 4.Reference
TypecreeperReference
Gears12 forward and 4 reverseReference
PTO & Hydraulics
PTO (claimed)31.3 kWReference
Hydraulic system37.9 LReference
Typeopen centerReference
Capacity37.9 LReference
Pump flow35.0 lpmReference
Rear TypeII/IReference
Controlposition and draft controlReference
Rear lift (at ends)1905 kgReference
Rear lift (at 24"/610mm)1500 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2295Reference
Capacities
Fuel66.2 LReference
Dimensions
Wheelbase199 cmReference
Weight3748 to 3968 poundsReference
Front tire6.5-16Reference
2WD Rear tire14.9-28Reference
2WD Standard tires (ag)Front: 6.5-16. Rear: 14.9-28Reference
4WD Standard tires (ag)Front: 9.5-22. Rear: 14.9-28Reference
2WD Length349 cmReference
4WD Length340 cmReference
Width170 cmReference
Height (ROPS)236 cmReference
2WD Weight1700 kgReference
4WD Weight1799 kgReference
Ground clearance41 cmReference
Kubota M4700 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Battery CCA615Reference
Battery volts12Reference
Attachment overview
Kubota LA1001 loaderReference
Kubota LA1002 loaderReference
Speeds
With 14.9-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
