Tractor · 2018Unverified
Kubota M5071N
Kubota M5071N — M5001 Series · 73 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
73 hp
Weight
5512 to 5952 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Orchard/Vineyard tractorReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post mid-mount folding ROPS. Cab optional.Reference
Engine
Kubota 3.8L 4-cyl dieselReference
Fuel tank76.1 LReference
Engine (gross)54.4 kWReference
Kubota V3800Reference
dieselReference
4-cylinder 16-valveReference
liquid-cooledReference
Displacement3.8 LReference
Bore/Stroke100 x 120 mmReference
Rated Power (gross)54.4 kWReference
Rated RPM2400Reference
Torque161.4 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Transmission
18-speedReference
36-speedReference
Gears18 forward and reverseReference
Clutchelectro-hydraulic wet discReference
Gears36 forward and reverseReference
PTO & Hydraulics
Valves2 to 5Reference
Pump flow62.8 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift (at ends)2300 kgReference
Rear PTOindependentReference
Rear PTO Type540/540EReference
Rear PTO Type1000Reference
Dimensions
Wheelbase213 cmReference
Weight5512 to 5952 poundsReference
Front tire280/70R18Reference
Rear tire440/65R28Reference
Standard tires (ag)Front: 280/70R18. Rear: 440/65R28Reference
Length394 cmReference
Width124 cmReference
Height (steering wheel)141 cmReference
Height (cab)235 cmReference
ROPS Weight2500 kgReference
Cab Weight2699 kgReference
Front tread103 to 132 cmReference
Rear tread93 to 146 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
