Tractor · 2016Unverified

Kubota M5091

Name: Kubota M5091
Brand: Kubota

Kubota M5091 — M5001 Series · 75 hp. Reference specifications; pending source verification.

The Kubota M5091 is a tractor characterised by a rated power of 75 hp, a mid-range figure for its class. It was manufactured from 2016 to 2020. Equipped with a 4-cylinder diesel liquid-cooled engine, this model features four-wheel drive and a 36-speed gearbox. Its listed operating weight is 3420 kg, with a capacity for operations up to 200 ac.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

75 hp

Weight

3420 kg

Catalogue coverage

Variants represented

Richest spec table

46 rows

Recorded power

75 hp

Recorded weight

3420 kg

Transmissions

36-speed

Production years

2016-2020

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Utility tractorReference

Four-wheel driveReference

Differential lockelectro-hydraulic rear, limited slip frontReference

Power steeringReference

Hydraulic wet disc brakesReference

Engine

Kubota 3.8L 4-cyl dieselReference

Fuel tank104.8 LReference

Exhaust fluid (DEF)12.1 LReference

Engine (gross)55.9 kWReference

Kubota V3800Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.8 LReference

Bore/Stroke100 x 120 mmReference

EmissionsStage IVReference

Rated Power (gross)55.9 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

36-speedReference

Gears36 forward and reverseReference

Clutchelectro-hydraulic wet discReference

PTO & Hydraulics

Valves2 to 4Reference

Pump flow64.0 lpmReference

Rear TypeIIReference

Controlposition and draft controlReference

Rear lift (at ends)4100 kgReference

Rear PTOindependentReference

Rear PTO Type540/540EReference

Rear PTO Type540/1000Reference

Dimensions

Wheelbase225 cmReference

Weight3420 kgReference

Front tire480/70R34Reference

Rear tire360/70R24Reference

Standard tires (ag)Front: 480/70R34. Rear: 360/70R24Reference

Length404 cmReference

Width219 cmReference

Height264 cmReference

Front tread155 to 166 cmReference

Rear tread144 to 179 cmReference

Kubota M5091 attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
