Tractor · 2016Unverified
Kubota M5111
Kubota M5111 — M5001 Series · 113 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
113 hp
Weight
3420 kg
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Utility tractorReference
Four-wheel driveReference
Differential lockelectro-hydraulic rear, limited slip frontReference
Power steeringReference
Hydraulic wet disc brakesReference
Engine
Kubota 3.8L 4-cyl dieselReference
Fuel tank104.8 LReference
Exhaust fluid (DEF)12.1 LReference
Engine (gross)84.3 kWReference
Kubota V3800Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.8 LReference
Bore/Stroke100 x 120 mmReference
EmissionsStage IVReference
Rated Power (gross)84.3 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
36-speedReference
Gears36 forward and reverseReference
Clutchelectro-hydraulic wet discReference
PTO & Hydraulics
Valves2 to 4Reference
Pump flow64.0 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift (at ends)4100 kgReference
Rear PTOindependentReference
Rear PTO Type540/540EReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase225 cmReference
Weight3420 kgReference
Front tire480/70R34Reference
Rear tire360/70R24Reference
Standard tires (ag)Front: 480/70R34. Rear: 360/70R24Reference
Length404 cmReference
Width219 cmReference
Height264 cmReference
Front tread155 to 166 cmReference
Rear tread144 to 179 cmReference
Kubota M5111 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
