Tractor · 1990Unverified

Kubota M5970

Name: Kubota M5970
Brand: Kubota

Kubota M5970 — Utility tractor · 66 hp. Reference specifications; pending source verification.

The Kubota M5970 is a tractor with a rated power output of 66 hp, positioned mid-range within its class. Produced between 1990 and 1998, the M5970 features a 3-cylinder diesel liquid-cooled engine, coupled with a hydrostatic transmission and four-wheel drive. Its listed weight is 2615 kg, and it is designed to handle tasks on areas of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

66 hp

Weight

2615 kg

Catalogue coverage

Variants represented

Richest spec table

51 rows

Recorded power

66 hp

Recorded weight

2615 kg

Production years

1990-1998

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Utility tractorReference

Four-wheel driveReference

Differential lockstandardReference

Steeringhydrostatic powerReference

Wet disc brakesReference

Four-post ROPS. Cab optional.Reference

Engine

Kubota 3.2L 3-cyl dieselReference

Fuel tank70.0 LReference

Engine (gross)49.2 kWReference

Engine (net)46.2 kWReference

Kubota D3200Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement3.2 LReference

Bore/Stroke109 x 115 mmReference

Power (net)46.2 kWReference

Power (gross)49.2 kWReference

Rated RPM2400Reference

Torque211.9 NmReference

Torque RPM1300Reference

StarterelectricReference

Starter volts12Reference

Oil capacity9.8 LReference

Coolant capacity11.6 LReference

PTO & Hydraulics

PTO (claimed)42.7 kWReference

Pressure181.3 barReference

Pump flow41.6 lpmReference

Rear TypeII/IReference

Controlposition and draft controlReference

Rear lift (at ends)2002 kgReference

Rear lift (at 24"/610mm)1500 kgReference

Rear PTOindependentReference

Clutchdry discReference

Rear PTO Type540/1000 (1.375)Reference

Dimensions

Wheelbase211 cmReference

Weight2615 kgReference

Front tire9.5-24Reference

Rear tire16.9-30Reference

Standard tires (ag)Front: 9.5-24. Rear: 16.9-30Reference

Length366 cmReference

Width184 cmReference

Height (exhaust)252 cmReference

Ground clearance37 cmReference

Front tread141 to 162 cmReference

Rear tread141 to 192 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Battery AH200Reference

Transmission

Clutchdry discReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
