Tractor · 2015Unverified

Kubota M6-111

Name: Kubota M6-111
Brand: Kubota

Kubota M6-111 — M6 Series · 114 hp. Reference specifications; pending source verification.

The Kubota M6-111 is a tractor with a rated power output of 114 horsepower, a mid-range figure for its class. It was manufactured in 2015. The M6-111 is equipped with a 4-cylinder turbocharged intercooled diesel liquid-cooled engine, paired with four-wheel drive and a powershift transmission. It has an operating weight of 4440 kg and is suited to operations spanning approximately 200 to 800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

114 hp

Max power

71.9 kW

Weight

4440 kg

Catalogue coverage

Variants represented

Richest spec table

111 rows

Recorded power

114 hp

Recorded weight

4440 kg

Transmissions

24-speed partial power shift

Production years

2015-2015

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Utility tractorReference

Four-wheel driveReference

Differential lockelectro-hydraulic front and rearReference

Power steeringReference

Hydraulic wet disc brakesReference

Grand X Cab standard with air-condiitoning.Reference

Engine

Kubota 3.8L 4-cyl dieselReference

Fuel tank190.0 LReference

Exhaust fluid (DEF)20.1 LReference

Engine (gross)85.1 kWReference

Engine (net)79.6 kWReference

Kubota V3800-TI-CRSReference

turbocharged intercooled dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.8 LReference

Bore/Stroke100 x 120 mmReference

EmissionsTier IVReference

Rated Power (net)79.6 kWReference

Rated Power (gross)85.1 kWReference

Fuel systemcommon rail direct injectionReference

Air cleanerdual dry elementReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Max power71.9 kWReference

Power at rated engine speed69.7 kWReference

Fuel TypeDieselReference

No of Cylinders4Reference

Rated engine speed2,600 rpmReference

AspirationTurbocharger with intercoolerReference

Bore and stroke100x120 mmReference

Transmission

24-speed partial power shiftReference

32-speed partial power shiftReference

TransmissionIntelli-ShiftReference

Typepartial power shiftReference

Gears24 forward and reverseReference

Clutchelectro-hydraulic wet discReference

Eight power shift gears in three ranges, with electro-hydraulic shuttle.Reference

TransmissionIntelli-Shift CreeperReference

Gears32 forward and reverseReference

Transmission TypeSemi-PowershiftReference

forward and reverse options32x32Reference

forward speed range37.7 kmphReference

Wheel Drive4WDReference

Clutch disk diameter wet clutch133 mmReference

PTO & Hydraulics

PTO (claimed)68.6 kWReference

PTO (tested)71.9 kWReference

Valves2 to 4Reference

Pump flow70.8 lpmReference

Steering flow60.6 lpmReference

Rear TypeIIReference

Controlelectronic lower-link draft sensingReference

Rear lift (at 24"/610mm)3099 kgReference

Rear lift (at 24"/610mm)4285 kgReference

Rear Armstelescopic lower link ends and stabilizersReference

Rear PTOindependentReference

Clutchhydraulic wet discReference

Rear PTO Type540/1000Reference

Engine RPM540@2405Reference

Engine RPM1000@2389Reference

Power at rated PTO speed71.5 kWReference

Dimensions

Wheelbase243 cmReference

Weight4440 kgReference

Front tire13.6R24Reference

Rear tire18.4R34Reference

Standard tires (ag)Front: 13.6R24. Rear: 18.4R34Reference

Length420 cmReference

Width210 cmReference

Height (cab)283 cmReference

Ground clearance49 cmReference

Front tread157 to 167 cmReference

Rear tread152 to 203 cmReference

Kubota M6-111 attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps130Reference

Battery volts12Reference

Battery size100 AhReference

Alternator size130 Amp/12 VReference

Test results

Diesel 24-speed 4WDJune 7 - 13, 2016Link: Nebraska Tractor Test 2153 fileReference

PTO performanceReference

Fuel use23.1 l/hourReference

Fuel use22.3 l/hourReference

General

Make & ModelKubota @ Common Rail System, direct injection, liquid-cooledReference

Creeper0.7 km/hReference

SCV controlJoystick: AvailableReference

Capacities

Capacity3,769 ccReference

Diesel exhaust fluid (DEF) tank16 LReference

Power

Rated Power114.1 HPReference

PTO

PTO Power92 hpReference

Rear PTO ControlHydraulically operatedReference

Rear PTO PowerYesReference

Rear PTO RPM1,000 RPMReference

Hydraulics

Pump Rated Output (total)131.3 l/minReference

Remote Valves4Reference

Steering & Implements flow60.4 lpm (70.9 lpm)Reference

Rear Hitch category (SAE designation)Category 2Reference

Dimensions & weight

Overall Height2,840 mmReference

Overall Length4,200 mmReference

Overall Width2,100 mmReference

Turning radius4 mReference

Overall weight4,440.2 kgReference

Wheels & tyres

Rear Wheel Type18.4 R34Reference

Rear wheel tread range2,040 mmReference

Front Wheel Type13.6 R24Reference

Front Wheel tread range1,680 mmReference

Operator station

Cab AvailabilitytrueReference

Seat SuspensiontrueReference

Steering & brakes

Steering typeHydrostatic power steeringReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
