Tractor · 2020Unverified
Kubota M6142
Kubota M6142 — M6002 Series · 142 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
142 hp
Weight
6000 kg
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Utility tractorReference
Four-wheel driveReference
Differential lockelectro-hydraulic front and rearReference
Cab standard with air-conditioning.Reference
Engine
Kubota 6.1L 4-cyl dieselReference
Fuel tank230.1 LReference
Exhaust fluid (DEF)20.1 LReference
Engine (gross)105.9 kWReference
Engine (max)120.1 kWReference
Kubota V6108Reference
turbocharged intercooled dieselReference
4-cylinder 16-valveReference
liquid-cooledReference
Displacement6.1 LReference
Bore/Stroke118 x 140 mmReference
Rated Power (gross)105.9 kWReference
Maximum Power (gross)120.1 kWReference
Rated RPM1900Reference
Torque645.0 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speed eight-speed power shiftReference
32-speed creeperReference
Typeeight-speed power shiftReference
Gears24 forward and reverseReference
Clutchelectro-hydraulic wet discReference
Eight power shift gears in three ranges with power shuttle.Reference
TypecreeperReference
Gears32 forward and reverseReference
PTO & Hydraulics
Typeclosed-center load-sensingReference
Valves3 or 4Reference
Pump flow115.1 lpmReference
Rear TypeIIIReference
Controllower-link draft sensingReference
Rear lift6999 kgReference
Front lift2318 kgReference
Rear PTOindependentReference
Rear PTO Type540/540E/1000/1000EReference
Front PTO Type1000Reference
Dimensions
Wheelbase268 cmReference
Weight6000 kgReference
Front tire420/70R24Reference
Rear tire520/70R38Reference
Standard tires (ag)Front: 420/70R24. Rear: 520/70R38Reference
Length462 cmReference
Width211 cmReference
Height (cab)289 cmReference
Shipping weight6000 kgReference
Ground clearance57 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps150Reference
Battery CCA1000Reference
Battery volts12Reference
Battery AH170Reference
Speeds
H8 is an overdrive gear, maximum speed at 1640 RPM.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
