Tractor · 1983Unverified
Kubota M6950
Kubota M6950 — M50 Series · 71 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
71 hp
Max power
41.1 kW
Weight
5778 to 7045 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Utility tractorReference
Built in JapanReference
Two- or four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Four-post ROPS. Cab optional with air-conditioning.Reference
Variants
M6950F2WDReference
M6950DT4WDReference
Engine
Kubota 4.0L 4-cyl dieselReference
Engine (net)52.9 kWReference
Drawbar (tested)41.1 kWReference
Kubota V4300-2AReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.0 LReference
Bore/Stroke105 x 115 mmReference
Power (net)52.9 kWReference
Air cleanersingle paper elementReference
Compression17:1Reference
Rated RPM2400Reference
Starter volts12Reference
Oil capacity13.2 LReference
Coolant capacity13.6 LReference
Power at rated engine speed49.5 kWReference
Max power41.1 kWReference
Transmission
12-speed synchronizedReference
TypesynchronizedReference
Gears12 forward and 4 reverseReference
Clutchsingle dry plateReference
Oil capacity50.0 LReference
Three gears (1-3) plus reverse in four ranges (A-D). Shifts between gears are synchronized.Reference
PTO & Hydraulics
PTO (claimed)49.2 kWReference
PTO (tested)49.5 kWReference
Hydraulic system50.0 LReference
Typeopen centerReference
Capacity50.0 LReference
Pressure181.3 barReference
Valves1 or 2Reference
Total flow41.6 lpmReference
Rear TypeIIReference
Rear lift (at ends)2199 kgReference
Rear lift (at 24"/610mm)2029 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Engine RPM540@2035Reference
Engine RPM1000@2389Reference
Power at rated PTO speed47.7 kWReference
Capacities
Fuel99.9 LReference
Dimensions
2WD Wheelbase238 cmReference
4WD Wheelbase241 cmReference
Weight5778 to 7045 poundsReference
Front tire7.50-16Reference
2WD Rear tire18.4-28Reference
2WD Standard tires (ag)Front: 7.50-16. Rear: 18.4-28Reference
4WD Standard tires (ag)Front: 11.2-24. Rear: 18.4-28Reference
Length388 cmReference
Width198 cmReference
2WD Height (exhaust)238 cmReference
4WD Height (exhaust)241 cmReference
2WD Clearance (front axle)53 cmReference
4WD Clearance (front axle)38 cmReference
2WD Front tread141 to 201 cmReference
4WD Front tread153 to 173 cmReference
Rear tread151 to 201 cmReference
2WD Shipping2620 kgReference
4WD Shipping3003 kgReference
Operating3195 kgReference
Ballasted4343 kgReference
Kubota M6950 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps65 (with cab)Reference
Battery volts12Reference
Battery AH300Reference
Test results
Diesel 12-speed 4WDSeptember 27 - October 13, 1983Link: Nebraska Tractor Test 1498 fileReference
PTO performanceReference
Fuel use15.5 l/hourReference
Fuel use14.4 l/hourReference
Drawbar performanceReference
Fuel use15.1 l/hourReference
Max pull3839 kgReference
Speeds
With 18.4-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
