Tractor · 1990Unverified

Kubota M6970

Name: Kubota M6970
Brand: Kubota

Kubota M6970 — Utility tractor · 77 hp. Reference specifications; pending source verification.

The Kubota M6970 is a tractor rated at 77 hp, positioning it within the middle range of its class in terms of power. Manufactured from 1990 to 1998, this model features a 4-cylinder diesel liquid-cooled engine that drives through a four-wheel drive system with a hydrostatic transmission. The listed weight of the Kubota M6970 is 3139 kg, and it is suited for tasks requiring approximately 200 acres of land.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

77 hp

Weight

3139 kg

Catalogue coverage

Variants represented

Richest spec table

51 rows

Recorded power

77 hp

Recorded weight

3139 kg

Production years

1990-1998

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Utility tractorReference

Four-wheel driveReference

Differential lockstandardReference

Steeringhydrostatic powerReference

Wet disc brakesReference

Four-post ROPS. Cab optional.Reference

Engine

Kubota 4.0L 4-cyl dieselReference

Fuel tank99.9 LReference

Engine (gross)57.4 kWReference

Engine (net)53.7 kWReference

Kubota V4000-2Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.0 LReference

Bore/Stroke105 x 115 mmReference

Power (net)53.7 kWReference

Power (gross)57.4 kWReference

Rated RPM2400Reference

Torque255.9 NmReference

Torque RPM1400Reference

StarterelectricReference

Starter volts12Reference

Oil capacity13.2 LReference

Coolant capacity13.6 LReference

PTO & Hydraulics

PTO (claimed)49.4 kWReference

Pressure181.3 barReference

Pump flow61.7 lpmReference

Rear TypeIIReference

Controlposition and draft controlReference

Rear lift (at ends)2699 kgReference

Rear lift (at 24"/610mm)2199 kgReference

Rear PTOindependentReference

Clutchhydraulic wet discReference

Rear PTO Type540/1000 (1.375)Reference

Dimensions

Wheelbase226 cmReference

Weight3139 kgReference

Front tire11.2-24Reference

Rear tire18.4-30Reference

Standard tires (ag)Front: 11.2-24. Rear: 18.4-30Reference

Length388 cmReference

Width184 cmReference

Height (exhaust)264 cmReference

Ground clearance38 cmReference

Front tread153 to 173 cmReference

Rear tread156 to 197 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Battery AH200Reference

Transmission

Clutchdry discReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
