Tractor · 2007Unverified

Kubota M7040HDN

Name: Kubota M7040HDN
Brand: Kubota

Kubota M7040HDN — Orchard/Vineyard tractor · 71 hp. Reference specifications; pending source verification.

The Kubota M7040HDN is a tractor with a rated output of 71 hp, placing it in the middle of its class in terms of power. This tractor, manufactured in 2007, features a 4-cylinder turbocharged diesel liquid-cooled engine, which transmits power through four-wheel drive via a hydrostatic transmission. The listed operating weight of the Kubota M7040HDN is between 4189 and 4806 pounds. It is designed for tasks on land areas of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

71 hp

Weight

4189 to 4806 pounds

Catalogue coverage

Variants represented

Richest spec table

81 rows

Recorded power

71 hp

Recorded weight

1900 kg

Transmissions

8-speed partially synchronized

Production years

2007-2007

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Orchard/Vineyard tractorReference

Original price$34,295 (2011)Reference

Four-wheel driveReference

Differential lockrear standardReference

Steeringhydrostatic powerReference

Mechanical wet disc brakesReference

Two-post foldable center ROPS. Cab optional with heat and air-conditioning. Optional radio/CD-player.Reference

Variants

M7040utility chassisReference

M7040HDNnarrow chassisReference

Engine

Kubota 3.3L 4-cyl dieselReference

Engine (net)52.9 kWReference

Kubota V3307DI-TReference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.3 LReference

EmissionsInterim Tier IVReference

Emission controlEGRReference

Power (net)52.9 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Oil capacity11.0 LReference

Coolant capacity8.0 LReference

Transmission

8-speed partially synchronizedReference

Typepartially synchronizedReference

Gears8 forward and reverseReference

Clutchwet discReference

Oil capacity40.1 LReference

Oil capacity51.9 LReference

Four synchronized gears in two ranges.Reference

PTO & Hydraulics

PTO (claimed)47.7 kWReference

Hydraulic system40.1 LReference

Hydraulic system51.9 LReference

Typeopen centerReference

Capacity40.1 LReference

Capacity51.9 LReference

Pressure191.0 barReference

Valves1 to 3Reference

Pump flow41.6 lpmReference

Total flow64.7 lpmReference

Steering flow23.1 lpmReference

Rear TypeII/IReference

Rear lift (at ends)1905 kgReference

Rear lift (at 24"/610mm)1500 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2160Reference

Capacities

Fuel60.2 LReference

Fuel76.1 LReference

Front axle8.5 LReference

Dimensions

Wheelbase204 cmReference

Weight4189 to 4806 poundsReference

Front tire8.00-16Reference

Rear tire12.4-24Reference

Standard tires (ag)Front: 8.00-16. Rear: 12.4-24Reference

Optional tires (ag)Front: 8.00-16. Rear: 12.4R24Reference

Optional tires (ag)Front: 8.00-16. Rear: 18.4-16.1Reference

Optional tires (ag)Front: 27x8.50-15. Rear: 320/85R20Reference

Optional tires (ag)Front: 9.5-16. Rear: 380/85R24Reference

Optional tires (ag)Front: 280/70R18. Rear: 480/65R24Reference

Length346 cmReference

Length345 cmReference

Width121 cmReference

Height (hood)116 cmReference

Height (cab)226 cmReference

Weight1900 kgReference

Weight2180 kgReference

Clearance (front axle)37 cmReference

Front tread103 cmReference

Rear tread89 to 138 cmReference

Kubota M7040HDN attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps45 (ROPS)Reference

Charging amps60 (cab)Reference

Charging amps80 (optional)Reference

Battery CCA700Reference

Battery volts12Reference

Attachment overview

The front-loader is only available on the M7040N with cab.Reference
