Tractor · 2009Unverified
Kubota M7040SU
Kubota M7040SU — Utility tractor · 68 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
68 hp
Weight
4475 to 4608 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Utility tractorReference
Two- or four-wheel driveReference
Differential lockrear standardReference
Power steeringReference
Mechanical wet disc brakesReference
Two-post foldable ROPS. Optional canopy.Reference
Variants
M7040SU2WDReference
M7040SUD4WDReference
M7040deluxe modelReference
M7040SUHDhydraulic shuttleReference
Engine
Kubota 3.3L 4-cyl dieselReference
Engine (net)50.7 kWReference
Kubota V3307Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Power (net)50.7 kWReference
Air cleanerdual dry elementReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity11.0 LReference
Coolant capacity8.0 LReference
Transmission
8-speed partially synchronizedReference
8-speed hydraulic shuttleReference
Typepartially synchronizedReference
Gears8 forward and 4 reverseReference
Clutch275mm dry discReference
Oil capacity43.9 LReference
Four gears in high, low, and reverse ranges. Synchronized forward-reverse shuttle shifting in low range, and synchronized shifting between gears 3 and 4.Reference
Typehydraulic shuttleReference
Clutchwet discReference
Four synchronized gears in high, low, and reverse ranges with left-hand hydraulic shuttle.Reference
PTO & Hydraulics
PTO (claimed)46.2 kWReference
Hydraulic system43.9 LReference
Typeopen centerReference
Capacity43.9 LReference
Valves0 to 3Reference
Pump flow41.6 lpmReference
Total flow64.7 lpmReference
Steering flow23.1 lpmReference
Rear TypeII/IReference
Rear lift (at ends)1905 kgReference
Rear lift (at 24"/610mm)1501 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2295Reference
Capacities
Fuel70.0 LReference
Front axle8.5 LReference
Dimensions
2WD Wheelbase208 cmReference
4WD Wheelbase205 cmReference
Weight4475 to 4608 poundsReference
Front tire7.50-16Reference
Rear tire16.9-30 (2WD)Reference
Standard tires (ag)Front: 7.50-16. Rear: 16.9-30 (2WD)Reference
Standard tires (ag)Front: 8.3-24. Rear: 14.9-28 (4WD)Reference
Optional tires (ag)Front: 9.5L-15. Rear: 16.9-30 (2WD)Reference
Lawn/turf front9.00-10Reference
Lawn/turf front9.5L-15Reference
Lawn/turf front305R343Reference
Lawn/turf front29x12.5-15Reference
Lawn/turf rear21.5L-16.1Reference
Lawn/turf rear18.4-26Reference
Lawn/turf rear570-648Reference
2WD Length355 cmReference
4WD Length334 cmReference
Width170 cmReference
Height (ROPS)246 cmReference
2WD Weight2029 kgReference
4WD Weight2090 kgReference
Clearance (front axle)46 cmReference
Clearance (front axle)50 cmReference
Front tread141 to 171 cmReference
Front tread141 to 151 cmReference
Rear tread141 to 0 cmReference
Kubota M7040SU attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps45Reference
Battery CCA700Reference
Battery volts12Reference
Attachment overview
Kubota LA1153 Height Position loaderReference
Kubota LA1153 Power Position loaderReference
BackhoeReference
Kubota BH92 Backhoe
Backhoe typeKubota BH92 BackhoeReference
Bucket width30 cmReference
Bucket width40 cmReference
Bucket width45 cmReference
Bucket width60 cmReference
Bucket width76 cmReference
Digging depth276 cmReference
Reach from pivot372 cmReference
Loading height242 cmReference
Bucket force1755 kgReference
Dipperstick force1176 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
