Tractor · 1979Unverified

Kubota M7500

Name: Kubota M7500
Brand: Kubota

Kubota M7500 — Utility tractor · 81 hp. Reference specifications; pending source verification.

The Kubota M7500 is a tractor with a rated power output of 81 hp, a mid-range figure for its class. It was manufactured from 1979 to 1986. The tractor features a 4-cylinder diesel liquid-cooled engine and four-wheel drive, paired with a 16-speed gearbox. Its operating weight ranges from 5082 to 5980 pounds, making it suitable for use on plots of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

81 hp

Max power

44.0 kW

Weight

5082 to 5980 pounds

Catalogue coverage

Variants represented

Richest spec table

84 rows

Recorded power

81 hp

Transmissions

16-speed

Production years

1979-1986

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Utility tractorReference

Built in JapanReference

Two- or four-wheel driveReference

SteeringpowerReference

Mechanical wet disc brakesReference

Two-post ROPS. Optional canopy.Reference

Variants

M7500DT4WDReference

Engine

Kubota 4.0L 4-cyl dieselReference

Fuel tank72.3 LReference

Engine (gross)60.4 kWReference

Drawbar (tested)44.0 kWReference

Kubota V4000 AReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.0 LReference

Bore/Stroke105 x 115 mmReference

Power (gross)60.4 kWReference

Air cleanersingle paper elementReference

Compression17.0:1Reference

Rated RPM2400Reference

Starter volts12Reference

Power at rated engine speed53.9 kWReference

Max power44.0 kWReference

Transmission

16-speedReference

Gears16 forward and 4 reverseReference

PTO & Hydraulics

PTO (claimed)53.7 kWReference

PTO (tested)53.9 kWReference

Typeopen centerReference

Valves1Reference

Total flow35.0 lpmReference

Rear TypeII/IReference

Rear lift (at ends)1696 kgReference

Rear PTOindependentReference

Rear PTO Type540/groundReference

Engine RPM540@2016Reference

Power at rated PTO speed49.6 kWReference

Dimensions

2WD Wheelbase215 cmReference

4WD Wheelbase217 cmReference

Weight5082 to 5980 poundsReference

Front tire7.50-16Reference

2WD Rear tire18.4-28Reference

2WD Standard tires (ag)Front: 7.50-16. Rear: 18.4-28Reference

4WD Standard tires (ag)Front: 11.2-24. Rear: 18.4-28Reference

2WD Length362 cmReference

4WD Length375 cmReference

2WD Width184 cmReference

4WD Width196 cmReference

2WD Height (exhaust)228 cmReference

4WD Height (exhaust)231 cmReference

2WD Clearance (front axle)46 cmReference

4WD Clearance (front axle)37 cmReference

2WD Front tread137 to 197 cmReference

4WD Front tread150 cmReference

Rear tread150 to 191 cmReference

2WD Shipping2305 kgReference

4WD Shipping2544 kgReference

4WD Operating2712 kgReference

Ballasted4313 kgReference

Kubota M7500 attachments

front-end loaderReference

M7500 Serial Numbers

Location:Serial number on the left side of the tractor's clutch housing.Reference

197910001 (M7500C)Reference

198010026 (M7500C)Reference

198110294 (M7500C)Reference

198210577 (M7500C)Reference

197810001 (M7500DT)Reference

197910401 (M7500DT)Reference

198010436 (M7500DT)Reference

198110761 (M7500DT)Reference

198211490 (M7500DT)Reference

198311744 (M7500DT)Reference

198450056 (M7500DT)Reference

198560011 (M7500DT)Reference

198669966 (M7500DT)Reference

FAQ: How to read a serial number table.Reference

Test results

Diesel 16-speed 4WDMay 13 - 27, 1980Link: Nebraska Tractor Test 1349 fileReference

PTO performanceReference

Fuel use16.3 l/hourReference

Fuel use14.0 l/hourReference

Drawbar performanceReference

Fuel use15.9 l/hourReference

Max pull3547 kgReference

Speeds

With 18.4-26 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
