Tractor · 1997Unverified
Kubota M8200
Kubota M8200 — M Series · 85 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
85 hp
Weight
5585 to 6615 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Utility tractorReference
Built in JapanReference
Two- or four-wheel driveReference
Final drivesinboard planetaryReference
Differential lockfront and rear standardReference
Steeringhydrostatic powerReference
Mechanical wet disc brakesReference
Two-post folding ROPS. Cab optional with air-conditioning.Reference
Engine
Kubota 3.3L 4-cyl dieselReference
Engine (gross)63.6 kWReference
Kubota V3300-TEReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke98 x 110 mmReference
Power (gross)63.6 kWReference
Air cleanerdual dry elementReference
Rated RPM2600Reference
Starter volts12Reference
Oil capacity10.7 LReference
Coolant capacity9.0 LReference
Transmission
8-speed synchronizedReference
8-speed power shuttleReference
TypesynchronizedReference
Gears8 forward and reverseReference
Clutch299.7mm cerametallic dry discReference
Oil capacity51.9 LReference
Typepower shuttleReference
Clutchhydraulic wet discReference
The hydraulic power shuttle transmission became available in 2003. A creeper option was also available increasing speeds to 12/12.Reference
PTO & Hydraulics
PTO (claimed)54.4 kWReference
Hydraulic system51.9 LReference
Typeopen centerReference
Capacity51.9 LReference
Valves1 to 3Reference
Pump flow64.7 lpmReference
Rear TypeIIReference
Controlposition control and top-link draft sensingReference
Rear lift (at ends)2522 kgReference
Rear lift (at 24"/610mm)2100 kgReference
Rear Armstelescopic stabilizers and link endsReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type540Reference
Rear PTO Type540/1000Reference
Capacities
ROPS Fuel90.1 LReference
Cab Fuel110.1 LReference
Dimensions
Wheelbase225 cmReference
Weight5585 to 6615 poundsReference
Front tire7.50-18Reference
2WD Rear tire12.4-24Reference
2WD Standard tires (ag)Front: 7.50-18. Rear: 12.4-24Reference
2WD Standard tires (ag)Front: 12.4-24. Rear: 18.4-30 (4WD)Reference
Lawn/turf front9.5L-15 (2WD)Reference
Lawn/turf rear18.4-26 (2WD)Reference
Industrial front27x8.50-15 (4WD)Reference
Industrial rear15-19.5 (4WD)Reference
2WD Length387 cmReference
4WD Length380 cmReference
Width198 cmReference
Height (ROPS)247 cmReference
Height (cab)247 cmReference
Clearance (front axle)50 cmReference
2WD Front tread144 to 203 cmReference
4WD Front tread141 to 151 cmReference
Rear tread151 to 192 cmReference
2WD ROPS2533 kgReference
4WD ROPS2732 kgReference
2WD Cab2800 kgReference
4WD Cab3000 kgReference
Kubota M8200 attachments
front-end loaderReference
Electrical
Charging systemalternatorReference
ROPS Charging amps45Reference
Cab Charging amps60Reference
Battery CCA1000Reference
Battery volts12Reference
Attachment overview
Kubota LA1251 loaderReference
Kubota LA1301 loaderReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
