Tractor · 2007Unverified
Kubota M8540HDN
Kubota M8540HDN — Orchard/Vineyard tractor · 86 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
86 hp
Weight
4343 to 4806 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Orchard/Vineyard tractorReference
Original price$36,551 (2011)Reference
Four-wheel driveReference
Differential lockrear standardReference
Steeringhydrostatic powerReference
Mechanical wet disc brakesReference
Two-post foldable center ROPS. Cab optional with heat and air-conditioning. Optional radio/CD-player.Reference
Variants
M8540utility chassisReference
M8540HDNnarrow chassisReference
Engine
Kubota 3.8L 4-cyl dieselReference
Engine (net)63.8 kWReference
Kubota V3800DI-TReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.8 LReference
Emission controlEGRReference
Power (net)63.8 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity8.0 LReference
Oil capacity10.7 LReference
Coolant capacity6.2 LReference
Coolant capacity9.0 LReference
Transmission
8-speed partially synchronizedReference
Typepartially synchronizedReference
Gears8 forward and reverseReference
Clutchwet discReference
Oil capacity40.1 LReference
Oil capacity51.9 LReference
Four synchronized gears in two ranges.Reference
PTO & Hydraulics
PTO (claimed)56.7 kWReference
Hydraulic system40.1 LReference
Hydraulic system51.9 LReference
Typeopen centerReference
Capacity40.1 LReference
Capacity51.9 LReference
Pressure191.0 barReference
Valves1 to 3Reference
Pump flow41.6 lpmReference
Total flow64.7 lpmReference
Steering flow23.1 lpmReference
Rear TypeII/IReference
Rear lift (at ends)1905 kgReference
Rear lift (at 24"/610mm)1500 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Engine RPM540@2160Reference
Capacities
Fuel60.2 LReference
Fuel76.1 LReference
Front axle8.5 LReference
Dimensions
Wheelbase204 cmReference
Weight4343 to 4806 poundsReference
Front tire8.00-16Reference
Rear tire12.4-24Reference
Standard tires (ag)Front: 8.00-16. Rear: 12.4-24Reference
Optional tires (ag)Front: 8.00-16. Rear: 12.4R24Reference
Optional tires (ag)Front: 8.00-16. Rear: 18.4-16.1Reference
Optional tires (ag)Front: 27x8.50-15. Rear: 320/85R20Reference
Optional tires (ag)Front: 9.5-16. Rear: 380/85R24Reference
Optional tires (ag)Front: 280/70R18. Rear: 480/65R24Reference
Length346 cmReference
Length350 cmReference
Width121 cmReference
Height (hood)116 cmReference
Height (cab)226 cmReference
Weight1969 kgReference
Weight2180 kgReference
Clearance (front axle)37 cmReference
Front tread103 cmReference
Rear tread89 to 138 cmReference
Kubota M8540HDN attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps45 (ROPS)Reference
Charging amps60 (cab)Reference
Charging amps80 (optional)Reference
Battery CCA700 (ROPS)Reference
Battery CCA900 (cab)Reference
Battery volts12Reference
Attachment overview
The front-loader is only available on the M7040N with cab.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
