Tractor · 1990Unverified

Kubota M8970

Name: Kubota M8970
Brand: Kubota

Kubota M8970 — Utility tractor · 105 hp. Reference specifications; pending source verification.

The Kubota M8970 is a tractor model rated at approximately 105 hp, a mid-range figure for its class. It was produced from 1990 to 1998. Key features of the M8970 include a 4-cylinder turbocharged diesel liquid-cooled engine and a four-wheel drive system with hydrostatic transmission. The tractor has an operating weight of 3499 kg and is suited to operations of 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

105 hp

Weight

3499 kg

Catalogue coverage

Variants represented

Richest spec table

51 rows

Recorded power

105 hp

Recorded weight

3499 kg

Production years

1990-1998

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Utility tractorReference

Four-wheel driveReference

Differential lockstandardReference

Steeringhydrostatic powerReference

Wet disc brakesReference

Four-post ROPS. Cab optional.Reference

Engine

Kubota 4.3L 4-cyl dieselReference

Fuel tank120.0 LReference

Engine (gross)77.9 kWReference

Engine (net)72.3 kWReference

Kubota V4300-T-AReference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.3 LReference

Bore/Stroke109 x 114 mmReference

Power (net)72.3 kWReference

Power (gross)77.9 kWReference

Rated RPM2400Reference

Torque336.6 NmReference

Torque RPM1200Reference

StarterelectricReference

Starter volts12Reference

Oil capacity15.4 LReference

Coolant capacity14.6 LReference

PTO & Hydraulics

PTO (claimed)63.4 kWReference

Pressure181.3 barReference

Pump flow61.7 lpmReference

Rear TypeIIReference

Controlposition and draft controlReference

Rear lift (at ends)2699 kgReference

Rear lift (at 24"/610mm)2199 kgReference

Rear PTOindependentReference

Clutchhydraulic wet discReference

Rear PTO Type540/1000 (1.375)Reference

Dimensions

Wheelbase246 cmReference

Weight3499 kgReference

Front tire12.4-24Reference

Rear tire18.4-34Reference

Standard tires (ag)Front: 12.4-24. Rear: 18.4-34Reference

Length406 cmReference

Width204 cmReference

Height (exhaust)292 cmReference

Ground clearance41 cmReference

Front tread164 to 173 cmReference

Rear tread157 to 205 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Battery AH200Reference

Transmission

Clutchdry discReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
