Tractor · 1984Unverified
Kubota M9570
Kubota M9570 — Utility tractor · 94 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
94 hp
Weight
6878 to 7594 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Utility tractorReference
Two- or four-wheel driveReference
Four-post ROPS.Reference
Engine
Kubota 4.3L 4-cylReference
Fuel tank120.0 LReference
Engine69.9 kWReference
Kubota V4300Reference
4-cylinderReference
liquid-cooledReference
Displacement4.3 LReference
Bore/Stroke109 x 115 mmReference
Power69.9 kWReference
Rated RPM2400Reference
Torque336.8 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Transmission
32-speedReference
Gears32 forward and 8 reverseReference
Four gears, plus reverse, in two ranges with additional creeper range and two-speed power shift.Reference
PTO & Hydraulics
Pump flow41.6 lpmReference
Rear TypeII/IReference
Rear lift3499 kgReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2036Reference
Engine RPM850@2391Reference
Dimensions
2WD Wheelbase243 cmReference
4WD Wheelbase246 cmReference
Weight6878 to 7594 poundsReference
Front tire7.50-20Reference
2WD Rear tire16.9-34Reference
2WD Standard tires (ag)Front: 7.50-20. Rear: 16.9-34Reference
4WD Standard tires (ag)Front: 11.2-24. Rear: 16.9-34Reference
2WD Length403 cmReference
4WD Length406 cmReference
2WD Width182 cmReference
4WD Width191 cmReference
2WD Weight3119 kgReference
4WD Weight3444 kgReference
2WD Ground clearance43 cmReference
4WD Ground clearance39 cmReference
2WD Front tread144 to 203 cmReference
4WD Front tread153/164 cmReference
Rear tread145 to 205 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Kubota M9570 Height
2WD ROPS264 cmReference
4WD ROPS261 cmReference
2WD Exhaust261 cmReference
4WD Exhaust258 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
