Tractor · 2007Unverified
Kubota M96SHDM Mudder
Kubota M96SHDM Mudder — High-Clearance tractor · 95 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
95 hp
Weight
7981 to 8157 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
High-Clearance tractorReference
Original price$53,380 (2011)Reference
Four-wheel driveReference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
Two-post ROPS. Optional canopy.Reference
Variants
M96Srow-crop chassisReference
Engine
Kubota 3.8L 4-cyl dieselReference
Engine (net)70.8 kWReference
Kubota V3800-DI-TE3Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.8 LReference
EmissionsTier IIIReference
Emission controlEGRReference
Power (net)70.8 kWReference
Air cleanerdual dry elementReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity10.7 LReference
Coolant capacity9.1 LReference
Transmission
24-speed partially synchronizedReference
TransmissionSwing Shift with CreeperReference
Typepartially synchronizedReference
Gears24 forward and reverseReference
Clutchwet discReference
Oil capacity62.8 LReference
PTO & Hydraulics
PTO (claimed)62.6 kWReference
Typeopen centerReference
Pressure196.1 barReference
Valves1 to 3Reference
Pump flow65.1 lpmReference
Total flow110.9 lpmReference
Steering flow45.8 lpmReference
Rear TypeIIReference
Rear lift (at ends)2522 kgReference
Rear lift (at 24"/610mm)2100 kgReference
Rear lift (at 24"/610mm)3397 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Rear PTO Type540/1000 (optional)Reference
Engine RPM540@2205Reference
Capacities
Fuel174.9 LReference
Front axle10.5 LReference
Dimensions
Wheelbase242 cmReference
Weight7981 to 8157 poundsReference
Front tire13.6-38Reference
Rear tire13.6-38Reference
Standard tires (ag)Front: 13.6-38. Rear: 13.6-38Reference
Optional tires (ag)Front: 230R95R48. Rear: 230R95R48Reference
Optional tires (ag)Front: 12.4R46. Rear: 12.4R46Reference
Length427 cmReference
Width202 cmReference
Height283 cmReference
Weight3620 kgReference
Weight3700 kgReference
Ground clearance69 cmReference
Clearance (front axle)76 cmReference
Front tread156 to 166 cmReference
Front tread182 to 202 cmReference
Rear tread154 to 164 cmReference
Rear tread186 to 205 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps45Reference
Charging amps80 (optional)Reference
Battery CCA900Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
