Tractor · 1995Unverified

Kubota MD97

Name: Kubota MD97
Brand: Kubota

Kubota MD97 — MD Series · 92 hp. Reference specifications; pending source verification.

The Kubota MD97 is a tractor model with an approximate rating of 92 hp, positioned in the mid-range of its class. This model was manufactured from 1995 to 2001. It features a 4-cylinder diesel liquid-cooled engine and a four-wheel drive system with a powershift transmission. The operating weight of the Kubota MD97 is between 7694 pounds and 8091 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

92 hp

Weight

7694 to 8091 pounds

Catalogue coverage

Variants represented

Richest spec table

55 rows

Recorded power

92 hp

Recorded weight

3489 kg

Transmissions

16-speed

Production years

1995-2001

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Utility tractorReference

Four-wheel driveReference

Cab standard with air-conditioning. Optional ROPS.Reference

Engine

Kubota 4.7L 4-cyl dieselReference

Fuel tank149.9 LReference

Engine71.4 kWReference

Kubota V4702Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.7 LReference

Bore/Stroke109 x 125 mmReference

Power71.4 kWReference

Rated RPM2400Reference

Torque358.0 NmReference

Torque RPM1400Reference

StarterelectricReference

Starter volts12Reference

Oil capacity16.3 LReference

Coolant capacity15.0 LReference

Transmission

16-speedReference

24-speed creeperReference

16-speed partial power shiftReference

Gears16 forward and reverseReference

Four gears (1-4) in two ranges (low/high) with additional two-range shift.Reference

TypecreeperReference

Gears24 forward and reverseReference

Optional creeper range added to basic transmission.Reference

Typepartial power shiftReference

Eight gears in two ranges. Optional creeper range available.Reference

PTO & Hydraulics

PTO (claimed)68.2 kWReference

Pump flow60.0 lpmReference

Rear TypeIIReference

Rear lift2034 kgReference

Rear lift2585 kgReference

Rear PTO Type540/1000 (1.375)Reference

Engine RPM540@2035Reference

Engine RPM1000@2211Reference

Dimensions

Wheelbase244 cmReference

Weight7694 to 8091 poundsReference

Front tire11.2-24Reference

Rear tire16.9-34Reference

Standard tires (ag)Front: 11.2-24. Rear: 16.9-34Reference

Length405 cmReference

Width198 cmReference

Height264 cmReference

ROPS Weight3489 kgReference

Cab Weight3670 kgReference

Ground clearance45 cmReference

Front tread132 to 151 cmReference

ROPS Rear tread137 to 199 cmReference

Cab Rear tread151 to 199 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
