Tractor · 2003Unverified
Kubota ME9000
Kubota ME9000 — ME Series · 94 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
94 hp
Weight
7561 to 8444 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Utility tractorReference
Four-wheel driveReference
Differential lockmechanical front and rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Trailer brakeshydraulicReference
Two-post sliding ROPS. Cab optional with air-conditioning.Reference
Variants
ME9000DTH-Llow-profileReference
Engine
Kubota 3.3L 4-cyl dieselReference
ROPS Fuel tank90.1 LReference
Cab Fuel tank110.1 LReference
Engine (gross)69.9 kWReference
Kubota V3300-TIEReference
turbocharged intercooled dieselReference
4-cylinderReference
liquid-cooled inlineReference
Displacement3.3 LReference
Bore/Stroke98 x 110 mmReference
Power (gross)69.9 kWReference
Air cleanerdual dry elementReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
18-speed power shuttleReference
Typepower shuttleReference
Gears18 forward and reverseReference
Clutchhydraulic wet discReference
Six synhcronized gears in three ranges with power shuttle.Reference
PTO & Hydraulics
PTO (claimed)60.6 kWReference
Valves2 or 3Reference
Pump flow64.3 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift (at ends)3999 kgReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase225 cmReference
Weight7561 to 8444 poundsReference
Front tire12.4R24Reference
Rear tire16.9R34Reference
Standard tires (ag)Front: 12.4R24. Rear: 16.9R34Reference
DTL Optional tires (ag)Front: 360/70R20. Rear: 480/70R28Reference
Length389 cmReference
Height (ROPS)252 cmReference
Height (cab)256 cmReference
Ground clearance46 cmReference
Front tread150 to 161 cmReference
Rear tread157 to 186 cmReference
ROPS3556 kgReference
Cab3830 kgReference
DTL3429 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
ROPS Charging amps45Reference
Cab Charging amps60Reference
Battery volts12Reference
Speeds
With 16.9R34 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
