Tractor · 2015Unverified
Kubota MR97-PC
Kubota MR97-PC — Rexia Series · 96 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
96 hp
Weight
3665 kg
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Half-track Crawler tractorReference
Drivehalf-trackReference
Power steeringReference
Mechanical wet disc brakesReference
Cab standard.Reference
Variants
MR97utilityReference
MR97-PChalf-trackReference
Engine
Kubota 3.8L 4-cyl dieselReference
Fuel tank110.1 LReference
Engine71.3 kWReference
Kubota V3800-CR-TE4Reference
turbocharged dieselReference
4-cylinder 16-valveReference
liquid-cooledReference
Displacement3.8 LReference
Bore/Stroke100 x 120 mmReference
Power71.3 kWReference
Rated RPM2600Reference
Starter typeelectricReference
Transmission
24-speedReference
Gears24 forward and reverseReference
Clutchelectro-hydraulic wet discReference
PTO & Hydraulics
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift3299 kgReference
Rear PTO Type540 (1.375)Reference
Engine RPM589@2600Reference
Engine RPM828@2600Reference
Engine RPM1170@2600Reference
Dimensions
Wheelbase270 cmReference
Weight3665 kgReference
Front tire9.5-24Reference
Rear tiretracksReference
Ag front9.5-24Reference
Ag front320/60-26Reference
Ag front360/70R20Reference
Ag rear450mm trackReference
Ag rear280mm trackReference
Length395 cmReference
Width198 cmReference
Height (cab)262 cmReference
Ground clearance48 cmReference
Front tread152 cmReference
Rear tread144 cmReference
Rear tread132 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
