Tractor · 2002Unverified
Kubota MX5000
Kubota MX5000 — MX Series · 52 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
52 hp
Weight
3284 to 3560 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Utility tractorReference
The Kubota MX5000 was marketed as an intermediate model between the L and M series line. It was less expensive than the similar M4900 and used a more basic transmission and hydraulic system.Reference
Two- or four-wheel driveReference
Final drivesspur gearReference
Differential lockmechanical rear lock standardReference
Steeringhydrostatic powerReference
Mechanical wet disc brakesReference
Two-post ROPS. Canopy optional.Reference
Variants
MX5000F2WDReference
MX5000DT4WDReference
MX5000SUbasic modelReference
Engine
Kubota 2.4L 4-cyl dieselReference
Fuel tank50.0 LReference
Engine (gross)38.9 kWReference
Engine (net)37.3 kWReference
Kubota V2403Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.4 LReference
Bore/Stroke87 x 102 mmReference
Power (net)37.3 kWReference
Power (gross)38.9 kWReference
Fuel systemindirect injectionReference
Air cleanerdry, dual elementReference
Rated RPM2700Reference
Starter volts12Reference
Oil capacity7.6 LReference
Coolant capacity7.5 LReference
Transmission
8-speed partially synchronizedReference
Typepartially synchronizedReference
Gears8 forward and 4 reverseReference
Clutchdry discReference
Synchronized shifting between gears 3 and 4.Reference
PTO & Hydraulics
PTO (claimed)32.8 kWReference
Valves3 (optional)Reference
Pump flow34.8 lpmReference
Total flow53.0 lpmReference
Rear Type2/1Reference
Controlposition controlReference
Controldraft control (optional)Reference
Rear lift (at ends)1300 kgReference
Rear lift (at 24"/610mm)1050 kgReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type540Reference
Dimensions
2WD Wheelbase181 cmReference
4WD Wheelbase180 cmReference
Weight3284 to 3560 poundsReference
Front tire7.5L-15Reference
Rear tire14.9-26Reference
Ag front7.5L-15 (2WD)Reference
Ag front9.5-16 (4WD)Reference
Ag rear14.9-26Reference
Lawn/turf front29x12.5-15Reference
Lawn/turf rear44x18-20Reference
Industrial front12-16.5Reference
Industrial rear17.5L-24Reference
Length336 cmReference
Length331 cmReference
Width158 cmReference
Height215 cmReference
Weight1489 kgReference
Weight1614 kgReference
Clearance (front axle)40 cmReference
Clearance (front axle)38 cmReference
2WD Front tread123 to 151 cmReference
4WD Front tread132 cmReference
Rear tread137 to 149 cmReference
Kubota MX5000 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps40Reference
Battery CCA582Reference
Battery volts12Reference
Attachment overview
Kubota LB702 loaderReference
Kubota LA852 loaderReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
