Tractor · 2010Unverified
Kubota MZ555-PC
Kubota MZ555-PC — SynerZ Series · 54 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
54 hp
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Half-track Crawler tractorReference
Drivehalf-trackReference
Power steeringReference
Mechanical wet disc brakesReference
Cab standard.Reference
Variants
MZ555utilityReference
MZ555-PChalf-trackReference
Engine
Kubota 3.6L 4-cyl dieselReference
Fuel tank90.1 LReference
Engine40.4 kWReference
Kubota V3600IDIReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.6 LReference
Bore/Stroke98 x 120 mmReference
Power40.4 kWReference
Rated RPM2400Reference
Starter typeelectricReference
Transmission
24-speedReference
Gears24 forward and reverseReference
Clutchelectro-hydraulic wet discReference
Eight gears (1-8) in three ranges (creeper, low, and high) with left-hand shuttle shift.Reference
PTO & Hydraulics
Rear TypeII/IReference
Controlposition and draft controlReference
Rear PTO Type540 (1.375)Reference
Engine RPM544@2400Reference
Engine RPM764@2400Reference
Engine RPM1080@2400Reference
Dimensions
Wheelbase204 cmReference
Front tire9.5-24Reference
Rear tiretracksReference
Ag front9.5-24Reference
Ag front320/60-26Reference
Ag rear450mm trackReference
Ag rear280mm trackReference
Length374 cmReference
Width188 cmReference
Width160 cmReference
Height (cab)257 cmReference
Ground clearance46 cmReference
Front tread119 to 149 cmReference
Rear tread144 cmReference
Rear tread132 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
