Tractor · 2006Unverified

Kubota MZ65-HPC

Name: Kubota MZ65-HPC
Brand: Kubota

Kubota MZ65-HPC — SynerZ Series · 64 hp. Reference specifications; pending source verification.

The Kubota MZ65-HPC is a tractor with an approximate output of 64 hp, positioning it in the lower end of its class. It was produced between 2006 and 2009. Key components include a 4-cylinder turbocharged diesel liquid-cooled engine and a tracked undercarriage coupled with a 24-speed gearbox; the tractor's operating weight is 3119 kg. It is designed for use on areas up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

64 hp

Weight

3119 kg

Catalogue coverage

Variants represented

Richest spec table

46 rows

Recorded power

64 hp

Recorded weight

3119 kg

Transmissions

24-speed

Production years

2006-2009

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Half-track Crawler tractorReference

Drivehalf-trackReference

Power steeringReference

Mechanical wet disc brakesReference

Cab standard.Reference

Variants

MZ65utilityReference

MZ65-HPChalf-trackReference

Engine

Kubota 3.3L 4-cyl dieselReference

Fuel tank90.1 LReference

Engine47.8 kWReference

Kubota V3300-TReference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.3 LReference

Bore/Stroke98 x 110 mmReference

Power47.8 kWReference

Rated RPM2600Reference

Starter typeelectricReference

Transmission

24-speedReference

Gears24 forward and reverseReference

Clutchelectro-hydraulic wet discReference

Eight gears (1-8) in three ranges (creeper, low, and high) with left-hand shuttle shift.Reference

PTO & Hydraulics

Rear TypeII/IReference

Controlposition and draft controlReference

Rear PTO Type540 (1.375)Reference

Engine RPM589@2600Reference

Engine RPM828@2600Reference

Engine RPM1170@2600Reference

Dimensions

Wheelbase215 cmReference

Weight3119 kgReference

Front tire9.5-24Reference

Rear tiretracksReference

Ag front9.5-24Reference

Ag front320/60-26Reference

Ag rear450mm trackReference

Ag rear280mm trackReference

Length362 cmReference

Width188 cmReference

Width160 cmReference

Height (cab)258 cmReference

Ground clearance46 cmReference

Front tread119 to 149 cmReference

Rear tread144 cmReference

Rear tread132 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
