Tractor · 2006Unverified
Kubota MZ65-HPC
Kubota MZ65-HPC — SynerZ Series · 64 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
64 hp
Weight
3119 kg
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Half-track Crawler tractorReference
Drivehalf-trackReference
Power steeringReference
Mechanical wet disc brakesReference
Cab standard.Reference
Variants
MZ65utilityReference
MZ65-HPChalf-trackReference
Engine
Kubota 3.3L 4-cyl dieselReference
Fuel tank90.1 LReference
Engine47.8 kWReference
Kubota V3300-TReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke98 x 110 mmReference
Power47.8 kWReference
Rated RPM2600Reference
Starter typeelectricReference
Transmission
24-speedReference
Gears24 forward and reverseReference
Clutchelectro-hydraulic wet discReference
Eight gears (1-8) in three ranges (creeper, low, and high) with left-hand shuttle shift.Reference
PTO & Hydraulics
Rear TypeII/IReference
Controlposition and draft controlReference
Rear PTO Type540 (1.375)Reference
Engine RPM589@2600Reference
Engine RPM828@2600Reference
Engine RPM1170@2600Reference
Dimensions
Wheelbase215 cmReference
Weight3119 kgReference
Front tire9.5-24Reference
Rear tiretracksReference
Ag front9.5-24Reference
Ag front320/60-26Reference
Ag rear450mm trackReference
Ag rear280mm trackReference
Length362 cmReference
Width188 cmReference
Width160 cmReference
Height (cab)258 cmReference
Ground clearance46 cmReference
Front tread119 to 149 cmReference
Rear tread144 cmReference
Rear tread132 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
