Tractor · 1965Unverified
Kubota RV Ridevator
Kubota RV Ridevator — Compact Utility tractor · 9 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
9 hp
Max power
5.0 kW
Weight
521 kg
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Built in JapanReference
Information on the Kubota Ridevator is scarce. The machine appears to have been sold in North America and Australia in the mid-to-late 1960s. Model numbers RV70 and RV90 are associated with the tractor.Reference
Two-wheel driveReference
SteeringmanualReference
Mechanical expanding shoe brakesReference
Open operator station.Reference
Engine
Kubota 0.6L 1-cyl gasolineReference
Kubota 0.7L 2-cyl dieselReference
Engine6.7 kWReference
Drawbar (tested)5.0 kWReference
KubotaReference
gasolineReference
1-cylinderReference
liquid-cooledReference
Displacement0.6 LReference
Bore/Stroke95 x 90 mmReference
Air cleaneroil bathReference
Compression5.7:1Reference
Rated RPM2000Reference
StarterelectricReference
Starter volts12Reference
dieselReference
2-cylinderReference
Displacement0.7 LReference
Power6.7 kWReference
Power at rated engine speed6.6 kWReference
Max power5.0 kWReference
Transmission
6-speed gearReference
Typebelt-driven gearReference
Gears6 forward and 2 reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (tested)6.6 kWReference
Dimensions
Wheelbase110 cmReference
Weight521 kgReference
Front tread67 to 83 cmReference
Rear tread64 to 89 cmReference
Test results
Gasoline 6-speed 2WDJuly 30 - August 6, 1965Link: Nebraska Tractor Test 906 fileReference
PTO performanceReference
Fuel use3.8 l/hourReference
Drawbar performanceReference
Gear 5 used for power test.Reference
Max pull327 kgReference
Gear 4 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
