Tractor · 2011Unverified

Kubota SMZ875

Name: Kubota SMZ875
Brand: Kubota

Kubota SMZ875 — Super SynerZ Series · 86 hp. Reference specifications; pending source verification.

The Kubota SMZ875 is a mid-range tractor with an approximate power rating of 86 hp, indicating its position within its class. Manufactured from 2011 to 2014, the SMZ875 features a 4-cylinder turbocharged diesel liquid-cooled engine, paired with a four-wheel drive system and a 24-speed gearbox. The tractor has an operating weight of 3250 kg, and it is designed to handle operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

86 hp

Weight

3250 kg

Catalogue coverage

Variants represented

Richest spec table

43 rows

Recorded power

86 hp

Recorded weight

3250 kg

Transmissions

24-speed

Production years

2011-2014

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerKubotaReference

Utility tractorReference

Four-wheel driveReference

Power steeringReference

Mechanical wet disc brakesReference

Cab standard.Reference

Variants

SMZ875utilityReference

SMZ875-PChalf-trackReference

Engine

Kubota 3.8L 4-cyl dieselReference

Fuel tank104.8 LReference

Engine64.0 kWReference

Kubota V3800-TReference

turbocharged dieselReference

4-cylinder 16-valveReference

liquid-cooledReference

Displacement3.8 LReference

Bore/Stroke100 x 120 mmReference

Power64.0 kWReference

Rated RPM2600Reference

Starter typeelectricReference

Transmission

24-speedReference

Gears24 forward and reverseReference

Clutchelectro-hydraulic wet discReference

Eight gears (1-8) in three ranges (creeper, low, and high) with left-hand shuttle shift.Reference

PTO & Hydraulics

Rear TypeIIReference

Controlposition and draft controlReference

Rear lift3299 kgReference

Rear PTO Type540 (1.375)Reference

Engine RPM589@2600Reference

Engine RPM828@2600Reference

Engine RPM1170@2600Reference

Dimensions

Wheelbase225 cmReference

Weight3250 kgReference

Front tire11.2-24Reference

Rear tire16.9-34Reference

Standard tires (ag)Front: 11.2-24. Rear: 16.9-34Reference

Length395 cmReference

Width194 cmReference

Height (cab)258 cmReference

Ground clearance47 cmReference

Front tread120 to 139 cmReference

Front tread133 to 151 cmReference

Rear tread131 to 199 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
