Tractor · 2011Unverified
Kubota SMZ875-PC
Kubota SMZ875-PC — Super SynerZ Series · 86 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
86 hp
Weight
3539 kg
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Half-track Crawler tractorReference
Drivehalf-trackReference
Power steeringReference
Mechanical wet disc brakesReference
Cab standard.Reference
Variants
SMZ875utilityReference
SMZ875-PChalf-trackReference
Engine
Kubota 3.8L 4-cyl dieselReference
Fuel tank90.1 LReference
Engine64.0 kWReference
Kubota V3800-TReference
turbocharged dieselReference
4-cylinder 16-valveReference
liquid-cooledReference
Displacement3.8 LReference
Bore/Stroke100 x 120 mmReference
Power64.0 kWReference
Rated RPM2600Reference
Starter typeelectricReference
Transmission
24-speedReference
Gears24 forward and reverseReference
Clutchelectro-hydraulic wet discReference
Eight gears (1-8) in three ranges (creeper, low, and high) with left-hand shuttle shift.Reference
PTO & Hydraulics
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift3299 kgReference
Rear PTO Type540 (1.375)Reference
Engine RPM589@2600Reference
Engine RPM828@2600Reference
Engine RPM1170@2600Reference
Dimensions
Wheelbase225 cmReference
Weight3539 kgReference
Front tire9.5-24Reference
Rear tiretracksReference
Ag front9.5-24Reference
Ag front320/60-26Reference
Ag rear450mm trackReference
Ag rear280mm trackReference
Length395 cmReference
Width188 cmReference
Width160 cmReference
Height (cab)258 cmReference
Ground clearance46 cmReference
Front tread152 cmReference
Rear tread144 cmReference
Rear tread132 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
