Tractor · 2015Unverified
Kubota STW34
Kubota STW34 — STW Series · 33 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
33 hp
Weight
2436 to 2756 pounds
Hover a source tag to verify
Overview
ManufacturerKubotaReference
Compact Utility tractorReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab optional with air-conditioning.Reference
Engine
Kubota 1.6L 3-cyl dieselReference
Fuel tank29.5 LReference
Engine (gross)24.5 kWReference
Engine (net)23.6 kWReference
Kubota D1703Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Bore/Stroke87 x 92 mmReference
Rated Power (net)23.6 kWReference
Rated Power (gross)24.5 kWReference
Rated RPM2700Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
PTO (claimed)16.6 kWReference
Pressure169.7 barReference
Pump flow29.9 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2670Reference
Engine RPM800@2717Reference
Engine RPM1000@2717Reference
Mid PTOindependentReference
Mid PTO Type2500Reference
Engine RPM2500@2734Reference
Dimensions
Wheelbase161 cmReference
Weight2436 to 2756 poundsReference
Front tire6.00-12Reference
Rear tire9.5-22Reference
Standard tires (ag)Front: 6.00-12. Rear: 9.5-22Reference
Lawn/turf front24x8.50-14Reference
Lawn/turf rear13.6-16Reference
Length294 cmReference
Width118 cmReference
Height (ROPS)234 cmReference
Height (cab)216 cmReference
ROPS Weight1104 kgReference
Cab Weight1250 kgReference
Ground clearance23 cmReference
Front tread102 cmReference
Rear tread94 to 106 cmReference
Kubota STW34 attachments
152 cm mid-mount mower deckReference
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Cab Charging amps60Reference
Battery volts12Reference
Attachment overview
152 cm mid-mount mower deckReference
Front-end loaderReference
60" Mower deck
Typemid-mount Kubota RCK-60Reference
Cutting width152 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
